4WIB | pdb_00004wib

Crystal structure of Magnesium transporter MgtE


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.20 Å
  • R-Value Free:
    0.268 (Depositor), 0.237 (DCC)
  • R-Value Work:
    0.240 (Depositor), 0.259 (DCC)
  • R-Value Observed:
    0.242 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4WIB

This is version 1.2 of the entry. See complete history

Literature

Structural basis for ion selectivity revealed by high-resolution crystal structure of Mg(2+) channel MgtE

Takeda, H.Hattori, M.Nishizawa, T.Yamashita, K.Shah, S.T.Caffrey, M.Maturana, A.D.Ishitani, R.Nureki, O.

(2014) Nat Commun 5: 5374-5374

  • DOI: https://doi.org/10.1038/ncomms6374
  • Primary Citation Related Structures:
    4U9L, 4U9N, 4WIB

  • PubMed Abstract:

    Magnesium is the most abundant divalent cation in living cells and is crucial to several biological processes. MgtE is a Mg(2+) channel distributed in all domains of life that contributes to the maintenance of cellular Mg(2+) homeostasis. Here we report the high-resolution crystal structures of the transmembrane domain of MgtE, bound to Mg(2+), Mn(2+) and Ca(2+). The high-resolution Mg(2+)-bound crystal structure clearly visualized the hydrated Mg(2+) ion within its selectivity filter. Based on those structures and biochemical analyses, we propose a cation selectivity mechanism for MgtE in which the geometry of the hydration shell of the fully hydrated Mg(2+) ion is recognized by the side-chain carboxylate groups in the selectivity filter. This is in contrast to the K(+)-selective filter of KcsA, which recognizes a dehydrated K(+) ion. Our results further revealed a cation-binding site on the periplasmic side, which regulate channel opening and prevents conduction of near-cognate cations.


  • Organizational Affiliation
    • 1] Department of Biological Sciences, Graduate School of Science, University of Tokyo, 2-11-16 Yayoi, Bunkyo-ku, Tokyo 113-0032, Japan [2] Global Research Cluster, RIKEN, 2-1 Hirosawa, Wako-shi, Saitama 351-0198, Japan.

Macromolecule Content

  • Total Structure Weight: 38.58 kDa
  • Atom Count: 2,610
  • Modeled Residue Count: 356
  • Deposited Residue Count: 356
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Magnesium transporter MgtE
A, B
178Thermus thermophilus HB8Mutation(s): 0
Gene Names: TTHA1060
Membrane Entity: Yes
UniProt
Find proteins for Q5SMG8 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q5SMG8
Go to UniProtKB:  Q5SMG8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5SMG8
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.20 Å
  • R-Value Free:  0.268 (Depositor), 0.237 (DCC)
  • R-Value Work:  0.240 (Depositor), 0.259 (DCC)
  • R-Value Observed: 0.242 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 64.12α = 90
b = 70.38β = 90
c = 103.34γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-12-03
    Type: Initial release
  • Version 1.1: 2020-02-05
    Changes: Data collection, Derived calculations, Other, Source and taxonomy, Structure summary
  • Version 1.2: 2024-03-20
    Changes: Data collection, Database references, Derived calculations, Refinement description
