4WG5 | pdb_00004wg5

Calcium-Dependent Protein Kinase 1 from Toxoplasma gondii (TgCDPK1) in complex with inhibitor UW1647

• PDB DOI: https://doi.org/10.2210/pdb4WG5/pdb

• Classification: TRANSFERASE/TRANSFERASE Inhibitor
• Organism(s): Toxoplasma gondii
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2014-09-17 Released: 2014-10-15
• Deposition Author(s): Merritt, E.A.
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:
  0.259 (Depositor), 0.256 (DCC)
• R-Value Work:
  0.220 (Depositor), 0.225 (DCC)
• R-Value Observed:
  0.222 (Depositor)

Literature

Calcium-Dependent Protein Kinase 1 from Toxoplasma gondii (TgCDPK1) in complex with inhibitor UW1647

Merritt, E.A., Maly, D.J., Ojo, K.K., Zhang, Z., Fan, E., Van Voorhis, W.C.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 55.63 kDa
• Atom Count: 3,845
• Modeled Residue Count: 464
• Deposited Residue Count: 484
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Calmodulin-domain protein kinase 1	A	484	Toxoplasma gondii	Mutation(s): 0  Gene Names: CDPK1 EC: 2.7.11.17 (PDB Primary Data), 2.7.11.1 (UniProt)
UniProt
Find proteins for Q9BJF5 (Toxoplasma gondii) Explore Q9BJF5  Go to UniProtKB:  Q9BJF5

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
UW3	B [auth A]	5-amino-3-[7-(cyclobutyloxy)quinolin-3-yl]-1-cyclohexyl-1H-pyrazole-4-carboxamide C23 H27 N5 O2 AJQKERUGIYLYDN-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:  0.259 (Depositor), 0.256 (DCC)
• R-Value Work:  0.220 (Depositor), 0.225 (DCC)
• R-Value Observed: 0.222 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 48.19	α = 90
b = 72.95	β = 102.48
c = 67.88	γ = 90

Software Package:

Software Name	Purpose
MOSFLM	data reduction
REFMAC	refinement
PDB_EXTRACT	data extraction
Aimless	data scaling

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2014-10-15
Deposition Author(s): Merritt, E.A.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	AI089441

Revision History

• Version 1.0: 2014-10-15
  Type: Initial release

• Version 1.1: 2015-02-04
  Changes: Derived calculations
• Version 1.2: 2017-09-27
  Changes: Author supporting evidence, Database references, Derived calculations, Other, Source and taxonomy
• Version 1.3: 2019-12-11
  Changes: Author supporting evidence
• Version 1.4: 2023-12-27
  Changes: Data collection, Database references, Refinement description
