4WFN

Crystal structure of the large ribosomal subunit (50S) of Deinococcus radiodurans containing a three residue insertion in L22 in complex with erythromycin


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.54 Å
  • R-Value Free: 0.282
  • R-Value Work: 0.234

wwPDB Validation 3D Report Full Report


This is version 2.0 of the entry. See complete history

Literature

The Ribosomal Protein uL22 Modulates the Shape of the Protein Exit Tunnel.

Wekselman, I.Zimmerman, E.Davidovich, C.Belousoff, M.Matzov, D.Krupkin, M.Rozenberg, H.Bashan, A.Friedlander, G.Kjeldgaard, J.Ingmer, H.Lindahl, L.Zengel, J.M.Yonath, A.

(2017) Structure 25: 1233-1241.e3

  • DOI: 10.1016/j.str.2017.06.004
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Erythromycin is a clinically useful antibiotic that binds to an rRNA pocket in the ribosomal exit tunnel. Commonly, resistance to erythromycin is acquired by alterations of rRNA nucleotides that interact with the drug. Mutations in the β hairpin of r ...

    Erythromycin is a clinically useful antibiotic that binds to an rRNA pocket in the ribosomal exit tunnel. Commonly, resistance to erythromycin is acquired by alterations of rRNA nucleotides that interact with the drug. Mutations in the β hairpin of ribosomal protein uL22, which is rather distal to the erythromycin binding site, also generate resistance to the antibiotic. We have determined the crystal structure of the large ribosomal subunit from Deinococcus radiodurans with a three amino acid insertion within the β hairpin of uL22 that renders resistance to erythromycin. The structure reveals a shift of the β hairpin of the mutated uL22 toward the interior of the exit tunnel, triggering a cascade of structural alterations of rRNA nucleotides that propagate to the erythromycin binding pocket. Our findings support recent studies showing that the interactions between uL22 and specific sequences within nascent chains trigger conformational rearrangements in the exit tunnel.


    Organizational Affiliation

    Department of Structural Biology, The Weizmann Institute of Science, Rehovot 7610001, Israel.,Department of Veterinary Disease Biology, University of Copenhagen, 1870 Frederiksbergc, Denmark.,Department of Biological Sciences, University of Maryland, Baltimore County, Baltimore, MD 21250, USA.,Department of Structural Biology, The Weizmann Institute of Science, Rehovot 7610001, Israel. Electronic address: ada.yonath@weizmann.ac.il.,The Ilana and Pascal Mantoux Institute for Bioinformatics, The Nancy and Stephen Grand Israel National Center for Personalized Medicine, Weizmann Institute of Science, Rehovot 7610001, Israel.




Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L2
A
275Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rplB
Find proteins for Q9RXJ9 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RXJ9
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L3
B
211Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rplC
Find proteins for Q9RXK2 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RXK2
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L4
C
205Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rplD
Find proteins for Q9RXK1 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RXK1
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L5
D
180Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rplE
Find proteins for Q9RXJ0 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RXJ0
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L6
E
185Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rplF
Find proteins for Q9RSL3 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RSL3
Entity ID: 6
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L13
G
174Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rplM
Find proteins for Q9RXY1 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RXY1
Entity ID: 7
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L14
H
134Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rplN
Find proteins for Q9RXJ2 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RXJ2
Entity ID: 8
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L15
I
156Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rplO
Find proteins for Q9RSK9 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RSK9
Entity ID: 9
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L16
J
141Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rplP
Find proteins for Q9RXJ5 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RXJ5
Entity ID: 10
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L17
K
116Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rplQ
Find proteins for Q9RSJ5 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RSJ5
Entity ID: 11
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L18
L
114Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rplR
Find proteins for Q9RSL2 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RSL2
Entity ID: 12
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L19
M
165Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rplS
Find proteins for Q9RWB4 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RWB4
Entity ID: 13
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L20
N
118Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rplT
Find proteins for Q9RSW7 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RSW7
Entity ID: 14
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L21
O
100Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rplU
Find proteins for Q9RY64 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RY64
Entity ID: 15
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L22,50S ribosomal protein L22
P
137Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rplV
Find proteins for Q9RXJ7 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RXJ7
Entity ID: 16
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L23
Q
95Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rplW
Find proteins for Q9RXK0 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RXK0
Entity ID: 17
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L24
R
115Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rplX
Find proteins for Q9RXJ1 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RXJ1
Entity ID: 18
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L25
S
237Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rplY (ctc)
Find proteins for Q9RX88 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RX88
Entity ID: 19
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L27
T
91Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rpmA
Find proteins for Q9RY65 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RY65
Entity ID: 20
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L28
U
81Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rpmB
Find proteins for Q9RRG8 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RRG8
Entity ID: 21
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L29
V
67Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rpmC
Find proteins for Q9RXJ4 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RXJ4
Entity ID: 22
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L30
W
55Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rpmD
Find proteins for Q9RSL0 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RSL0
Entity ID: 23
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L32
Z
60Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rpmF
Find proteins for P49228 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  P49228
Entity ID: 24
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L33
1
55Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rpmG
Find proteins for Q9RSS4 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RSS4
Entity ID: 25
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L34
2
47Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rpmH
Find proteins for Q9RSH2 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RSH2
Entity ID: 26
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L35
3
65Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 0
Gene Names: rpmI
Find proteins for Q9RSW6 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RSW6
Entity ID: 27
MoleculeChainsLengthOrganism
23S ribosomal RNAX2880Deinococcus radiodurans R1
Entity ID: 28
MoleculeChainsLengthOrganism
5S ribosomal RNAY124Deinococcus radiodurans R1
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
MG
Query on MG

Download SDF File
Download CCD File
A, B, K, M, X
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
ERY
Query on ERY

Download SDF File
Download CCD File
X
ERYTHROMYCIN A
C37 H67 N O13
ULGZDMOVFRHVEP-RWJQBGPGSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.54 Å
  • R-Value Free: 0.282
  • R-Value Work: 0.234
  • Space Group: I 2 2 2
Unit Cell:
Length (Å)Angle (°)
a = 170.092α = 90.00
b = 411.588β = 90.00
c = 695.883γ = 90.00
Software Package:
Software NamePurpose
HKL-2000data reduction
PDB_EXTRACTdata extraction
PHENIXrefinement
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2015-12-23
    Type: Initial release
  • Version 1.1: 2016-01-20
    Type: Structure summary
  • Version 2.0: 2017-08-16
    Type: Atomic model, Database references, Derived calculations
