4WAI

Structural characterization of the late competence protein ComFB from Bacillus subtilis.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.43 Å
  • R-Value Free: 0.251
  • R-Value Work: 0.208
  • R-Value Observed: 0.212

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

Structural characterization of the late competence protein ComFB from Bacillus subtilis.

Sysoeva, T.A.Bane, L.B.Xiao, D.Y.Bose, B.Chilton, S.S.Gaudet, R.Burton, B.M.

(2015) Biosci Rep 35

  • DOI: 10.1042/BSR20140174
  • Primary Citation of Related Structures:
    4WAI

  • PubMed Abstract:
  • Many bacteria take up DNA from their environment as part of the process of natural transformation. DNA uptake allows microorganisms to gain genetic diversity and can lead to the spread of antibiotic resistance or virulence genes within a microbial po ...

    Many bacteria take up DNA from their environment as part of the process of natural transformation. DNA uptake allows microorganisms to gain genetic diversity and can lead to the spread of antibiotic resistance or virulence genes within a microbial population. Development of genetic competence (Com) in Bacillus subtilis is a highly regulated process that culminates in expression of several late competence genes and formation of the DNA uptake apparatus. The late competence operon comF encodes a small protein of unknown function, ComFB. To gain insight into the function of ComFB, we determined its 3D structure via X-ray crystallography. ComFB is a dimer and each subunit consists of four α-helices connected by short loops and one extended β-strand-like stretch. Each subunit contains one zinc-binding site formed by four cysteines, which are unusually spaced in the primary sequence. Using structure- and bioinformatics-guided substitutions we analyzed the inter-subunit interface of the ComFB dimer. Based on these analyses, we conclude that ComFB is an obligate dimer. We also characterized ComFB in vivo and found that this protein is produced in competent cells and is localized to the cytosol. Consistent with previous reports, we showed that deletion of ComFB does not affect DNA uptake function. Combining our results, we conclude that ComFB is unlikely to be a part of the DNA uptake machinery under tested conditions and instead may have a regulatory function.


    Organizational Affiliation

    *Department of Molecular and Cellular Biology, Harvard University, Cambridge, MA 02138, U.S.A.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
ComF operon protein 2ABCD121Bacillus subtilis subsp. subtilis str. 168Mutation(s): 0
Gene Names: comFBcomF2BSU35460
Find proteins for P39146 (Bacillus subtilis (strain 168))
Explore P39146
Go to UniProtKB:  P39146
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download CCD File
A, B, C, D
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.43 Å
  • R-Value Free: 0.251
  • R-Value Work: 0.208
  • R-Value Observed: 0.212
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 41.483α = 90
b = 123.579β = 93.92
c = 41.759γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesP41 GM103403
Department of Energy (DOE, United States)United StatesDE-AC02-06CH11357

Revision History

  • Version 1.0: 2014-12-10
    Type: Initial release
  • Version 1.1: 2015-05-06
    Changes: Database references
  • Version 1.2: 2017-08-23
    Changes: Data collection, Derived calculations, Other, Refinement description, Source and taxonomy, Structure summary
  • Version 1.3: 2017-09-06
    Changes: Author supporting evidence
  • Version 1.4: 2019-12-04
    Changes: Author supporting evidence
