4UIG

Structure of the copper sensitive operon repressor from Streptomyces lividans at pH6


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.234
  • R-Value Work: 0.211
  • R-Value Observed: 0.212

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structural Insights Into Conformational Switching in the Copper Metalloregulator Csor from Streptomyces Lividans

Porto, T.V.Hough, M.A.Worrall, J.A.R.

(2015) Acta Crystallogr D Biol Crystallogr 71: 1872

  • DOI: https://doi.org/10.1107/S1399004715013012
  • Primary Citation of Related Structures:
    4UIG

  • PubMed Abstract:

    Copper-sensitive operon repressors (CsoRs) act to sense cuprous ions and bind them with a high affinity under copper stress in many bacteria. The binding of copper(I) leads to a conformational change in their homotetramer structure, causing disassembly of the operator DNA-CsoR complex and evoking a transcriptional response. Atomic-level structural insight into the conformational switching mechanism between the apo and metal-bound states is lacking. Here, a new X-ray crystal structure of the CsoR from Streptomyces lividans is reported and compared with a previously reported S. lividans CsoR X-ray structure crystallized under different conditions. Based on evidence from this new X-ray structure, it is revealed that the conformational switching between states centres on a concertina effect at the C-terminal end of each α2 helix in the homotetramer. This drives the Cys104 side chain, a copper(I)-ligating residue, into a position enabling copper(I) coordination and as a result disrupts the α2-helix geometry, leading to a compacting and twisting of the homotetramer structure. Strikingly, the conformational switching induces a redistribution of electrostatic surface potential on the tetrameric DNA-binding face, which in the copper(I)-bound state would no longer favour interaction with the mode of operator DNA binding.


  • Organizational Affiliation

    School of Biological Sciences, University of Essex, Wivenhoe Park, Colchester CO4 3SQ, England.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
COPPER SENSITIVE OPERON REPRESSOR136Streptomyces lividansMutation(s): 0
UniProt
Find proteins for D6EK73 (Streptomyces lividans TK24)
Explore D6EK73
Go to UniProtKB:  D6EK73
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD6EK73
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.234
  • R-Value Work: 0.211
  • R-Value Observed: 0.212
  • Space Group: I 41 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 89.74α = 90
b = 89.74β = 90
c = 103.86γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
MOSFLMdata reduction
Aimlessdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2015-09-09
    Type: Initial release
  • Version 1.1: 2015-09-16
    Changes: Database references
  • Version 1.2: 2024-01-10
    Changes: Data collection, Database references, Derived calculations, Other, Refinement description
