4TRZ

Structure of BACE1 complex with 2-thiophenyl HEA-type inhibitor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.25 Å
  • R-Value Free: 0.295
  • R-Value Work: 0.263
  • R-Value Observed: 0.265

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Evaluation of transition-state mimics in a superior BACE1 cleavage sequence as peptide-mimetic BACE1 inhibitors

Hattori, Y.Kobayashi, K.Deguchi, A.Nohara, Y.Akiyama, T.Teruya, K.Sanjoh, A.Nakagawa, A.Yamashita, E.Akaji, K.

(2015) Bioorg Med Chem 23: 5626-5640

  • DOI: 10.1016/j.bmc.2015.07.023
  • Primary Citation of Related Structures:
    4TRZ, 4TRW

  • PubMed Abstract:
  • A superior substrate sequence for BACE1 containing transition-state mimics at the scissile site was evaluated as a protease inhibitor. Hydroxymethylcarbonyl (HMC) and hydroxyethylamine (HEA) isosteres were selected as the transition state mimics, and ...

    A superior substrate sequence for BACE1 containing transition-state mimics at the scissile site was evaluated as a protease inhibitor. Hydroxymethylcarbonyl (HMC) and hydroxyethylamine (HEA) isosteres were selected as the transition state mimics, and incorporated into the scissile site of the superior sequence covering the P4 to P1' sites (Glu-Ile-Thi-Thi(*)Nva; (*)denotes the cleavage site). Isosteres having different absolute configurations of the hydroxyl group were synthesized separately, and the effect of the configuration was evaluated. Configuration of the hydroxyl group of each isostere showed a marked effect on the inhibitory activity; anti-configuration to the scissile site substituent had potent inhibitory activity in an HMC-type inhibitor, whereas anti-configuration of HEA-type inhibitors showed no inhibitory activity. Structural evaluations based on X-ray crystallographic analyses of recombinant BACE1 in complex with each inhibitor provided insights into the protein-ligand interactions, especially at the prime sites.


    Organizational Affiliation

    Department of Medicinal Chemistry, Kyoto Pharmaceutical University, Yamashina-ku, Kyoto 607-8412, Japan. Electronic address: akaji@mb.kyoto-phu.ac.jp.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Beta-secretase 1ABC388Homo sapiensMutation(s): 0
Gene Names: BACE1BACEKIAA1149
EC: 3.4.23.46
Find proteins for P56817 (Homo sapiens)
Explore P56817
Go to UniProtKB:  P56817
NIH Common Fund Data Resources
PHAROS  P56817
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
  • Find similar proteins by:  Sequence   |   Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
2-thiophenyl HEA-type inhibitorDEF4synthetic constructMutation(s): 0
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
TIH
Query on TIH
D,E,FL-PEPTIDE LINKINGC7 H9 N O2 SALA
Biologically Interesting Molecules (External Reference) 1 Unique
Entity ID: 2
IDChainsNameType/Class2D Diagram3D Interactions
PRD_002107
Query on PRD_002107
D, E, F2-thiophenyl HEA-type inhibitorPeptide-like /  Enzyme inhibitor

--

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.25 Å
  • R-Value Free: 0.295
  • R-Value Work: 0.263
  • R-Value Observed: 0.265
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 81.872α = 90
b = 102.42β = 103.49
c = 101.587γ = 90
Software Package:
Software NamePurpose
DENZOdata collection
SCALEPACKdata reduction
MOLREPmodel building
REFMACrefinement
PDB_EXTRACTdata extraction
DENZOdata reduction
SCALEPACKdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2015-07-01
    Type: Initial release
  • Version 1.1: 2015-09-02
    Changes: Database references
  • Version 1.2: 2015-09-09
    Changes: Database references
  • Version 1.3: 2020-01-29
    Changes: Data collection, Database references, Derived calculations
