Crystal structure of protease-associated domain of Arabidopsis vacuolar sorting receptor 1

Experimental Data Snapshot

  • Resolution: 1.65 Å
  • R-Value Free: 0.190
  • R-Value Work: 0.166
  • R-Value Observed: 0.168

wwPDB Validation   3D Report Full Report

This is version 1.2 of the entry. See complete history


How vacuolar sorting receptor proteins interact with their cargo proteins: crystal structures of apo and cargo-bound forms of the protease-associated domain from an Arabidopsis vacuolar sorting receptor.

Luo, F.Fong, Y.H.Zeng, Y.Shen, J.Jiang, L.Wong, K.B.

(2014) Plant Cell 26: 3693-3708

  • DOI: https://doi.org/10.1105/tpc.114.129940
  • Primary Citation of Related Structures:
    4TJV, 4TJX

  • PubMed Abstract:

    In plant cells, soluble proteins are directed to vacuoles because they contain vacuolar sorting determinants (VSDs) that are recognized by vacuolar sorting receptors (VSR). To understand how a VSR recognizes its cargo, we present the crystal structures of the protease-associated domain of VSR isoform 1 from Arabidopsis thaliana (VSR1PA) alone and complexed with a cognate peptide containing the barley (Hordeum vulgare) aleurain VSD sequence of 1ADSNPIRPVT10. The crystal structures show that VSR1PA binds the sequence, Ala-Asp-Ser, preceding the NPIR motif. A conserved cargo binding loop, with a consensus sequence of 95RGxCxF100, forms a cradle that accommodates the cargo-peptide. In particular, Arg-95 forms a hydrogen bond to the Ser-3 position of the VSD, and the essential role of Arg-95 and Ser-3 in receptor-cargo interaction was supported by a mutagenesis study. Cargo binding induces conformational changes that are propagated from the cargo binding loop to the C terminus via conserved residues in switch I-IV regions. The resulting 180° swivel motion of the C-terminal tail is stabilized by a hydrogen bond between Glu-24 and His-181. A mutagenesis study showed that these two residues are essential for cargo interaction and trafficking. Based on our structural and functional studies, we present a model of how VSRs recognize their cargos.

  • Organizational Affiliation

    Centre for Protein Science and Crystallography, The Chinese University of Hong Kong, Shatin, New Territories, Hong Kong, China Centre for Cell and Developmental Biology and State Key Laboratory of Agrobiotechnology, School of Life Sciences, The Chinese University of Hong Kong, Shatin, New Territories, Hong Kong, China.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Vacuolar-sorting receptor 1165Arabidopsis thalianaMutation(s): 0
Gene Names: VSR1BP80BELPELP1At3g52850F8J2.20
Find proteins for P93026 (Arabidopsis thaliana)
Explore P93026
Go to UniProtKB:  P93026
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP93026
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 1.65 Å
  • R-Value Free: 0.190
  • R-Value Work: 0.166
  • R-Value Observed: 0.168
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 32.6α = 90
b = 62.68β = 109.39
c = 35.81γ = 90
Software Package:
Software NamePurpose
XDSdata scaling

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
General Research Fund from the Research Grants Council of Hong Kong SARHong Kong476212

Revision History  (Full details and data files)

  • Version 1.0: 2014-12-10
    Type: Initial release
  • Version 1.1: 2017-11-22
    Changes: Advisory, Database references, Derived calculations, Other, Refinement description, Source and taxonomy
  • Version 1.2: 2023-12-27
    Changes: Data collection, Database references, Refinement description
