4RNL | pdb_00004rnl

The crystal structure of a possible galactose mutarotase from Streptomyces platensis subsp. rosaceus

PDB DOI: https://doi.org/10.2210/pdb4RNL/pdb

Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
Organism(s): Streptomyces platensis
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2014-10-24 Released: 2014-11-26
Deposition Author(s): Tan, K., Li, H., Endres, M., Phillips Jr., G.N., Joachimiak, A., Midwest Center for Structural Genomics (MCSG), Enzyme Discovery for Natural Product Biosynthesis (NatPro)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.192 (Depositor), 0.192 (DCC)
R-Value Work:
0.154 (Depositor), 0.155 (DCC)
R-Value Observed:
0.156 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

The crystal structure of a possible galactose mutarotase from Streptomyces platensis subsp. rosaceus

Tan, K., Li, H., Endres, M., Phillips Jr., G.N., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 146.07 kDa
Atom Count: 11,778
Modeled Residue Count: 1,363
Deposited Residue Count: 1,372
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
possible galactose mutarotase	A, B, C, D	343	Streptomyces platensis	Mutation(s): 0 EC: 5.1.3.3
UniProt
Find proteins for A0A0B4J187 (Streptomyces platensis) Explore A0A0B4J187 Go to UniProtKB: A0A0B4J187
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A0B4J187
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PO4 Query on PO4 Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain L [auth B] SDF format, chain M [auth B] SDF format, chain N [auth B] SDF format, chain P [auth C] SDF format, chain Q [auth C] SDF format, chain S [auth D] SDF format, chain T [auth D] SDF format, chain U [auth D] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain L [auth B] MOL2 format, chain M [auth B] MOL2 format, chain N [auth B] MOL2 format, chain P [auth C] MOL2 format, chain Q [auth C] MOL2 format, chain S [auth D] MOL2 format, chain T [auth D] MOL2 format, chain U [auth D] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain L [auth B] mmCIF format, chain M [auth B] mmCIF format, chain N [auth B] mmCIF format, chain P [auth C] mmCIF format, chain Q [auth C] mmCIF format, chain S [auth D] mmCIF format, chain T [auth D] mmCIF format, chain U [auth D]	G [auth A] H [auth A] I [auth A] L [auth B] M [auth B] G [auth A], H [auth A], I [auth A], L [auth B], M [auth B], N [auth B], P [auth C], Q [auth C], S [auth D], T [auth D], U [auth D]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B] Focus chain P [auth C] Focus chain Q [auth C] Focus chain S [auth D] Focus chain T [auth D] Focus chain U [auth D] Interactions & Density Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B] Focus chain P [auth C] Focus chain Q [auth C] Focus chain S [auth D] Focus chain T [auth D] Focus chain U [auth D]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain J [auth B] SDF format, chain K [auth B] SDF format, chain O [auth C] SDF format, chain R [auth D] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain J [auth B] MOL2 format, chain K [auth B] MOL2 format, chain O [auth C] MOL2 format, chain R [auth D] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain J [auth B] mmCIF format, chain K [auth B] mmCIF format, chain O [auth C] mmCIF format, chain R [auth D]	E [auth A] F [auth A] J [auth B] K [auth B] O [auth C] E [auth A], F [auth A], J [auth B], K [auth B], O [auth C], R [auth D]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain O [auth C] Focus chain R [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain O [auth C] Focus chain R [auth D]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B, C, D	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.192 (Depositor), 0.192 (DCC)
R-Value Work: 0.154 (Depositor), 0.155 (DCC)
R-Value Observed: 0.156 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 47.425	α = 90
b = 115.8	β = 90
c = 261.345	γ = 90

Software Package:

Software Name	Purpose
SBC-Collect	data collection
SHELXD	phasing
MLPHARE	phasing
DM	model building
DENZO	data reduction
SCALEPACK	data scaling
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
DM	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2014-11-26

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Enzyme Discovery for Natural Product Biosynthesis (NatPro)

Revision History (Full details and data files)

Version 1.0: 2014-11-26
Type: Initial release
Version 1.1: 2017-11-22
Changes: Refinement description
Version 1.2: 2024-10-30
Changes: Data collection, Database references, Derived calculations, Structure summary
