4RMO | pdb_00004rmo

Crystal Structure of the CptIN Type III Toxin-Antitoxin System from Eubacterium rectale


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free:
    0.234 (Depositor), 0.246 (DCC)
  • R-Value Work:
    0.199 (Depositor), 0.212 (DCC)
  • R-Value Observed:
    0.201 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4RMO

This is version 1.3 of the entry. See complete history

Literature

Co-evolution of quaternary organization and novel RNA tertiary interactions revealed in the crystal structure of a bacterial protein-RNA toxin-antitoxin system.

Rao, F.Short, F.L.Voss, J.E.Blower, T.R.Orme, A.L.Whittaker, T.E.Luisi, B.F.Salmond, G.P.

(2015) Nucleic Acids Res 43: 9529-9540

  • DOI: https://doi.org/10.1093/nar/gkv868
  • Primary Citation Related Structures:
    4RMO

  • PubMed Abstract:

    Genes encoding toxin-antitoxin (TA) systems are near ubiquitous in bacterial genomes and they play key roles in important aspects of bacterial physiology, including genomic stability, formation of persister cells under antibiotic stress, and resistance to phage infection. The CptIN locus from Eubacterium rectale is a member of the recently-discovered Type III class of TA systems, defined by a protein toxin suppressed by direct interaction with a structured RNA antitoxin. Here, we present the crystal structure of the CptIN protein-RNA complex to 2.2 Å resolution. The structure reveals a new heterotetrameric quaternary organization for the Type III TA class, and the RNA antitoxin bears a novel structural feature of an extended A-twist motif within the pseudoknot fold. The retention of a conserved ribonuclease active site as well as traits normally associated with TA systems, such as plasmid maintenance, implicates a wider functional role for Type III TA systems. We present evidence for the co-variation of the Type III component pair, highlighting a distinctive evolutionary process in which an enzyme and its substrate co-evolve.


  • Organizational Affiliation
    • Department of Biochemistry, University of Cambridge, Cambridge CB2 1QW, UK.

Macromolecule Content

  • Total Structure Weight: 267.95 kDa
  • Atom Count: 19,477
  • Modeled Residue Count: 1,600
  • Deposited Residue Count: 1,600
  • Unique protein chains: 1
  • Unique nucleic acid chains: 1

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
CptN Toxin
A, C, E, G, I
A, C, E, G, I, K, M, O
155Agathobacter rectalis DSM 17629Mutation(s): 0
Gene Names: cptNEUR_02830
Find similar nucleic acids by:  (by identity cutoff)
Entity ID: 2
MoleculeChains LengthOrganismImage
RNA (45-MER)
B, D, F, H, J
B, D, F, H, J, L, N, P
45synthetic construct
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
CA

Query on CA



Download:Ideal Coordinates CCD File
AA [auth D]
AB [auth L]
BA [auth D]
BB [auth L]
CA [auth D]
AA [auth D],
AB [auth L],
BA [auth D],
BB [auth L],
CA [auth D],
CB [auth M],
DA [auth E],
DB [auth N],
EA [auth F],
EB [auth N],
FA [auth F],
FB [auth N],
GA [auth F],
GB [auth N],
HA [auth F],
HB [auth N],
IA [auth G],
IB [auth O],
JA [auth H],
JB [auth P],
KA [auth H],
KB [auth P],
LA [auth H],
LB [auth P],
MA [auth H],
NA [auth H],
OA [auth H],
PA [auth I],
Q [auth A],
QA [auth J],
R [auth B],
RA [auth J],
S [auth B],
SA [auth J],
T [auth B],
TA [auth J],
U [auth B],
UA [auth J],
V [auth B],
VA [auth J],
W [auth C],
WA [auth K],
X [auth D],
XA [auth L],
Y [auth D],
YA [auth L],
Z [auth D],
ZA [auth L]
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A, C, E, G, I
A, C, E, G, I, K, M, O
L-PEPTIDE LINKINGC5 H11 N O2 SeMET

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free:  0.234 (Depositor), 0.246 (DCC)
  • R-Value Work:  0.199 (Depositor), 0.212 (DCC)
  • R-Value Observed: 0.201 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 63.11α = 90
b = 185.891β = 92.63
c = 138.78γ = 90
Software Package:
Software NamePurpose
Aimlessdata scaling
SOLVEphasing
REFMACrefinement
PDB_EXTRACTdata extraction
GDAdata collection
MOSFLMdata reduction
SCALAdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2015-09-30
    Type: Initial release
  • Version 1.1: 2015-10-14
    Changes: Database references
  • Version 1.2: 2015-11-18
    Changes: Database references
  • Version 1.3: 2024-11-06
    Changes: Data collection, Database references, Derived calculations, Refinement description, Structure summary
