4RDQ

Calcium-activated chloride channel bestrophin-1, from chicken, in complex with Fab antibody fragments, chloride and calcium


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.85 Å
  • R-Value Free: 0.234
  • R-Value Work: 0.217
  • R-Value Observed: 0.218

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history


Literature

Structure and insights into the function of a Ca(2+)-activated Cl(-) channel.

Kane Dickson, V.Pedi, L.Long, S.B.

(2014) Nature 516: 213-218

  • DOI: https://doi.org/10.1038/nature13913
  • Primary Citation of Related Structures:
    4RDQ

  • PubMed Abstract:

    Bestrophin calcium-activated chloride channels (CaCCs) regulate the flow of chloride and other monovalent anions across cellular membranes in response to intracellular calcium (Ca(2+)) levels. Mutations in bestrophin 1 (BEST1) cause certain eye diseases. Here we present X-ray structures of chicken BEST1-Fab complexes, at 2.85 Å resolution, with permeant anions and Ca(2+). Representing, to our knowledge, the first structure of a CaCC, the eukaryotic BEST1 channel, which recapitulates CaCC function in liposomes, is formed from a pentameric assembly of subunits. Ca(2+) binds to the channel's large cytosolic region. A single ion pore, approximately 95 Å in length, is located along the central axis and contains at least 15 binding sites for anions. A hydrophobic neck within the pore probably forms the gate. Phenylalanine residues within it may coordinate permeating anions via anion-π interactions. Conformational changes observed near the 'Ca(2+) clasp' hint at the mechanism of Ca(2+)-dependent gating. Disease-causing mutations are prevalent within the gating apparatus.


  • Organizational Affiliation

    Structural Biology Program, Memorial Sloan Kettering Cancer Center, 1275 York Avenue, New York, New York 10065, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Bestrophin-1
A, B, C, D, E
409Gallus gallusMutation(s): 0
Gene Names: Best1 bestrophin-1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Fab antibody fragment, light chain
F, H, J, L, N
212Mus musculusMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Fab antibody fragment, heavy chain
G, I, K, M, O
217Mus musculusMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
C6N
Query on C6N

Download Ideal Coordinates CCD File
CA [auth B],
KA [auth C],
QA [auth D],
V [auth A],
XA [auth E]
6-cyclohexyl-2-(4-cyclohexylbutyl)-2-({[4-O-(alpha-D-glucopyranosyl)-beta-D-glucopyranosyl]oxy}methyl)hexyl 4-O-alpha-D-glucopyranosyl-beta-D-glucopyranoside
C47 H84 O22
IBVSQWFQEONEKZ-VWHTXWAPSA-N
GOL
Query on GOL

Download Ideal Coordinates CCD File
DA [auth C],
LA [auth D],
P [auth A],
RA [auth E],
W [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
CA
Query on CA

Download Ideal Coordinates CCD File
EA [auth C],
MA [auth D],
S [auth A],
SA [auth E],
X [auth B]
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
K
Query on K

Download Ideal Coordinates CCD File
BA [auth B],
IA [auth C],
JA [auth C],
U [auth A],
WA [auth E]
POTASSIUM ION
K
NPYPAHLBTDXSSS-UHFFFAOYSA-N
CL
Query on CL

Download Ideal Coordinates CCD File
AA [auth B]
FA [auth C]
GA [auth C]
HA [auth C]
NA [auth D]
AA [auth B],
FA [auth C],
GA [auth C],
HA [auth C],
NA [auth D],
OA [auth D],
PA [auth D],
Q [auth A],
R [auth A],
T [auth A],
TA [auth E],
UA [auth E],
VA [auth E],
Y [auth B],
Z [auth B]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.85 Å
  • R-Value Free: 0.234
  • R-Value Work: 0.217
  • R-Value Observed: 0.218
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 98.54α = 90
b = 242.904β = 93.68
c = 172.757γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
SHARPphasing
CNSrefinement
REFMACrefinement
CBASSdata collection
HKL-3000data reduction
HKL-3000data scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-10-22
    Type: Initial release
  • Version 1.1: 2014-10-29
    Changes: Structure summary
  • Version 1.2: 2014-12-24
    Changes: Database references
  • Version 1.3: 2019-07-17
    Changes: Data collection, Refinement description
  • Version 1.4: 2024-11-20
    Changes: Data collection, Database references, Derived calculations, Structure summary
