4R14

Crystal structure of human CSN6 MPN domain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.601 Å
  • R-Value Free: 0.259
  • R-Value Work: 0.225

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Crystal structure of the human CSN6 MPN domain

Ma, X.L.Xu, M.Jiang, T.

(2014) Biochem.Biophys.Res.Commun. 453: 25-30

  • DOI: 10.1016/j.bbrc.2014.09.046

  • PubMed Abstract:
  • The mammalian COP9 signalosome is an eight-subunit (CSN1-CSN8) complex that plays essential roles in multiple cellular and physiological processes. CSN5 and CSN6 are the only two MPN (Mpr1-Pad1-N-terminal) domain-containing subunits in the complex. U ...

    The mammalian COP9 signalosome is an eight-subunit (CSN1-CSN8) complex that plays essential roles in multiple cellular and physiological processes. CSN5 and CSN6 are the only two MPN (Mpr1-Pad1-N-terminal) domain-containing subunits in the complex. Unlike the CSN5 MPN domain, CSN6 lacks a metal-binding site and isopeptidase activity. Here, we report the crystal structure of the human CSN6 MPN domain. Each CSN6 monomer contains nine β sheets surrounded by three helices. Two forms of dimers are observed in the crystal structure. Interestingly, a domain swapping of β8 and β9 strands occurs between two neighboring monomers to complete a typical MPN fold. Analyses of the pseudo metal-binding motif in CSN6 suggest that the loss of two key histidine residues may contribute to the lack of catalytic activity in CSN6. Comparing the MPN domain of our CSN6 with that in the CSN complex shows that apart from the different β8-β9 conformation, they have minor conformational differences at two insertion regions (Ins-1 and Ins-2). Besides, the interacting mode of CSN6-CSN6 in our structure is distinct from that of CSN5-CSN6 in the CSN complex structure. Moreover, the functional implications for Ins-1 and Ins-2 are discussed.


    Organizational Affiliation

    National Laboratory of Biomacromolecules, Institute of Biophysics, Chinese Academy of Sciences, Beijing 100101, China; University of Chinese Academy of Sciences, 19A Yuquan Road, Shijingshan District, Beijing 100039, China.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
COP9 signalosome complex subunit 6
A, B
181Homo sapiensMutation(s): 0
Gene Names: COPS6 (CSN6, HVIP)
Find proteins for Q7L5N1 (Homo sapiens)
Go to Gene View: COPS6
Go to UniProtKB:  Q7L5N1
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
HG
Query on HG

Download SDF File
Download CCD File
A, B
MERCURY (II) ION
Hg
BQPIGGFYSBELGY-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.601 Å
  • R-Value Free: 0.259
  • R-Value Work: 0.225
  • Space Group: P 32
Unit Cell:
Length (Å)Angle (°)
a = 66.552α = 90.00
b = 66.552β = 90.00
c = 86.829γ = 120.00
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data collection
HKL-2000data reduction
HKL-2000data scaling
SOLVEphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2014-10-22
    Type: Initial release
