4R0R

Ebolavirus GP Prehairpin Intermediate Mimic


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.15 Å
  • R-Value Free: 0.294
  • R-Value Work: 0.272

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Design and characterization of ebolavirus GP prehairpin intermediate mimics as drug targets.

Clinton, T.R.Weinstock, M.T.Jacobsen, M.T.Szabo-Fresnais, N.Pandya, M.J.Whitby, F.G.Herbert, A.S.Prugar, L.I.McKinnon, R.Hill, C.P.Welch, B.D.Dye, J.M.Eckert, D.M.Kay, M.S.

(2015) Protein Sci. 24: 446-463

  • DOI: 10.1002/pro.2578

  • PubMed Abstract:
  • Ebolaviruses are highly lethal filoviruses that cause hemorrhagic fever in humans and nonhuman primates. With no approved treatments or preventatives, the development of an anti-ebolavirus therapy to protect against natural infections and potential w ...

    Ebolaviruses are highly lethal filoviruses that cause hemorrhagic fever in humans and nonhuman primates. With no approved treatments or preventatives, the development of an anti-ebolavirus therapy to protect against natural infections and potential weaponization is an urgent global health need. Here, we describe the design, biophysical characterization, and validation of peptide mimics of the ebolavirus N-trimer, a highly conserved region of the GP2 fusion protein, to be used as targets to develop broad-spectrum inhibitors of ebolavirus entry. The N-trimer region of GP2 is 90% identical across all ebolavirus species and forms a critical part of the prehairpin intermediate that is exposed during viral entry. Specifically, we fused designed coiled coils to the N-trimer to present it as a soluble trimeric coiled coil as it appears during membrane fusion. Circular dichroism, sedimentation equilibrium, and X-ray crystallography analyses reveal the helical, trimeric structure of the designed N-trimer mimic targets. Surface plasmon resonance studies validate that the N-trimer mimic binds its native ligand, the C-peptide region of GP2. The longest N-trimer mimic also inhibits virus entry, thereby confirming binding of the C-peptide region during viral entry and the presence of a vulnerable prehairpin intermediate. Using phage display as a model system, we validate the suitability of the N-trimer mimics as drug screening targets. Finally, we describe the foundational work to use the N-trimer mimics as targets in mirror-image phage display, which will be used to identify D-peptide inhibitors of ebolavirus entry.


    Organizational Affiliation

    Department of Biochemistry, University of Utah School of Medicine, Salt Lake City, Utah, 84112-5650.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
eboIZN21
A
50N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Small Molecules
Modified Residues  2 Unique
IDChainsTypeFormula2D DiagramParent
NH2
Query on NH2
A
NON-POLYMERH2 N

--

ACE
Query on ACE
A
NON-POLYMERC2 H4 O

--

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.15 Å
  • R-Value Free: 0.294
  • R-Value Work: 0.272
  • Space Group: P 3 2 1
Unit Cell:
Length (Å)Angle (°)
a = 38.510α = 90.00
b = 38.510β = 90.00
c = 72.588γ = 120.00
Software Package:
Software NamePurpose
PDB_EXTRACTdata extraction
HKL-2000data reduction
PHENIXrefinement
PHASERphasing
ADSCdata collection
SCALEPACKdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2014-10-22
    Type: Initial release
  • Version 1.1: 2015-04-15
    Type: Database references
