Biological Assembly 1

Global Symmetry: Cyclic - C2  (3D View)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 73.33 kDa
• Atom Count: 5,124
• Modelled Residue Count: 620
• Deposited Residue Count: 682
• Unique protein chains: 1

 4QVA

Unliganded crystal structure of Feline Norovirus P Domain co-crystallized with N-glycolylneuraminic acid

• PDB DOI: 10.2210/pdb4QVA/pdb

• Classification: VIRAL PROTEIN
• Organism(s): Norovirus cat/GIV.2/CU081210E/USA/2010
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2014-07-14 Released: 2014-11-19
• Deposition Author(s): Singh, B.K., Hansman, G.S.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.18 Å
• R-Value Free: 0.228
• R-Value Work: 0.196
• R-Value Observed: 0.198

Literature

Structural analysis of a feline norovirus protruding domain.

Singh, B.K., Glatt, S., Ferrer, J.L., Koromyslova, A.D., Leuthold, M.M., Dunder, J., Hansman, G.S.

(2015) Virology 474: 181-185

• PubMed: 25463616
• DOI: 10.1016/j.virol.2014.10.028
• Primary Citation of Related Structures:
  4QUZ, 4QV2, 4QVA, 4QVJ


• PubMed Abstract:


Norovirus infects different animals, including humans, mice, dogs, and cats. Here, we show an X-ray crystal structure of a feline GIV.2 norovirus capsid-protruding (P) domain to 2.35Å resolution. The feline GIV.2 P domain was reminiscent of human norovirus P domains, except for a novel P2 subdomain α-helix and an extended P1 subdomain interface loop. These new structural features likely obstructed histo-blood group antigens, which are attachment factors for human norovirus, from binding at the equivalent sites on the feline GIV.2 P domain. Additionally, an ELISA showed that the feline GIV.2 was antigenically distinct from a human GII.10 norovirus.

---

Organizational Affiliation:

Schaller Research Group at the University of Heidelberg and the DKFZ, Heidelberg 69120, Germany; Department of Infectious Diseases, Virology, University of Heidelberg, Heidelberg 69120, Germany. Electronic address: [e-mail].

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
VP1	A, B	341	Norovirus cat/GIV.2/CU081210E/USA/2010	Mutation(s): 0  Gene Names: JF781268
UniProt
Find proteins for H8YRY9 (Norovirus cat/GIV.2/CU081210E/USA/2010) Explore H8YRY9  Go to UniProtKB:  H8YRY9

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.18 Å
• R-Value Free: 0.228
• R-Value Work: 0.196
• R-Value Observed: 0.198
• Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 57.53	α = 90
b = 99.38	β = 111.04
c = 69.34	γ = 90

Software Package:

Software Name	Purpose
XSCALE	data scaling
PHASER	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data scaling
XDS	data reduction

Structure Validation

Entry History

Deposition Data

• Released Date: 2014-11-19
Deposition Author(s): Singh, B.K., Hansman, G.S.

Revision History

• Version 1.0: 2014-11-19
  Type: Initial release

• Version 1.1: 2015-03-04
  Changes: Database references
