4QCA | pdb_00004qca

Crystal structure of Vaccinia virus uracil-DNA glycosylase mutant R167AD4

PDB DOI: https://doi.org/10.2210/pdb4QCA/pdb

Classification: HYDROLASE
Organism(s): Vaccinia virus Ankara
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2014-05-09 Released: 2015-05-13
Deposition Author(s): Sartmatova, D., Nash, T., Schormann, N., Nuth, M., Ricciardi, R., Banerjee, S., Chattopadhyay, D.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free:
0.236 (Depositor), 0.242 (DCC)
R-Value Work:
0.204 (Depositor), 0.210 (DCC)
R-Value Observed:
0.206 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

Crystallization and preliminary X-ray diffraction analysis of three recombinant mutants of Vaccinia virus uracil DNA glycosylase.

Sartmatova, D., Nash, T., Schormann, N., Nuth, M., Ricciardi, R., Banerjee, S., Chattopadhyay, D.

(2013) Acta Crystallogr Sect F Struct Biol Cryst Commun 69: 295-301

PubMed: 23519808 Search on PubMed Search on PubMed Central
DOI: https://doi.org/10.1107/S1744309113002716
Primary Citation Related Structures:
4QCA

PubMed Abstract:
Amino-acid residues located at a highly flexible area in the uracil DNA glycosylase of Vaccinia virus were mutated. In the crystal structure of wild-type D4 these residues lie at the dimer interface. Specifically, three mutants were generated: (i) residue Arg167 was replaced with an alanine (R167AD4), (ii) residues Glu171, Ser172 and Pro173 were substituted with three glycine residues (3GD4) and (iii) residues Glu171 and Ser172 were deleted (Δ171-172D4). Mutant proteins were expressed, purified and crystallized in order to investigate the effects of these mutations on the structure of the protein.

Organizational Affiliation

Science and Technology Honors Program, University of Alabama at Birmingham, Birmingham, AL 35294, USA.

Macromolecule Content

Total Structure Weight: 101.66 kDa
Atom Count: 7,691
Modeled Residue Count: 881
Deposited Residue Count: 884
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uracil-DNA glycosylase	A, B, C, D	221	Vaccinia virus Ankara	Mutation(s): 2 Gene Names: ACAM3000_MVA_101, D4, MVA101R, UNG EC: 3.2.2.27
UniProt
Find proteins for P04303 (Vaccinia virus (strain Western Reserve)) Explore P04303 Go to UniProtKB: P04303
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P04303
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain I [auth C] SDF format, chain K [auth D] SDF format, chain L [auth D] MOL2 format, chain E [auth A] MOL2 format, chain I [auth C] MOL2 format, chain K [auth D] MOL2 format, chain L [auth D] mmCIF format, chain E [auth A] mmCIF format, chain I [auth C] mmCIF format, chain K [auth D] mmCIF format, chain L [auth D]	E [auth A], I [auth C], K [auth D], L [auth D]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain I [auth C] Focus chain K [auth D] Focus chain L [auth D] Interactions & Density Focus chain E [auth A] Focus chain I [auth C] Focus chain K [auth D] Focus chain L [auth D]
K Query on K Download:Ideal Coordinates CCD File SDF format, chain G [auth A] MOL2 format, chain G [auth A] mmCIF format, chain G [auth A]	G [auth A]	POTASSIUM ION K NPYPAHLBTDXSSS-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Interactions & Density Focus chain G [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain H [auth B] SDF format, chain J [auth C] SDF format, chain M [auth D] MOL2 format, chain F [auth A] MOL2 format, chain H [auth B] MOL2 format, chain J [auth C] MOL2 format, chain M [auth D] mmCIF format, chain F [auth A] mmCIF format, chain H [auth B] mmCIF format, chain J [auth C] mmCIF format, chain M [auth D]	F [auth A], H [auth B], J [auth C], M [auth D]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain F [auth A] Focus chain H [auth B] Focus chain J [auth C] Focus chain M [auth D] Interactions & Density Focus chain F [auth A] Focus chain H [auth B] Focus chain J [auth C] Focus chain M [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.236 (Depositor), 0.242 (DCC)
R-Value Work: 0.204 (Depositor), 0.210 (DCC)
R-Value Observed: 0.206 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 72.14	α = 90
b = 118.268	β = 90
c = 121.97	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PDB_EXTRACT	data extraction
RAPD	data collection
XDS	data reduction
SCALA	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2015-05-13

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2015-05-13
Type: Initial release
Version 1.1: 2016-06-29
Changes: Source and taxonomy
Version 1.2: 2023-09-20
Changes: Data collection, Database references, Derived calculations, Refinement description
