Crystal Structure of Catalytic Core domain of FIV Integrase

Experimental Data Snapshot

  • Resolution: 1.84 Å
  • R-Value Free: 0.222
  • R-Value Work: 0.171
  • R-Value Observed: 0.174

wwPDB Validation   3D Report Full Report

This is version 1.1 of the entry. See complete history


Identification of phe187 as a crucial dimerization determinant facilitates crystallization of a monomeric retroviral integrase core domain.

Galilee, M.Alian, A.

(2014) Structure 22: 1512-1519

  • DOI: https://doi.org/10.1016/j.str.2014.08.001
  • Primary Citation of Related Structures:
    4MQ3, 4PA1

  • PubMed Abstract:

    Retroviral DNA integration into the host genome is mediated by nucleoprotein assemblies containing tetramers of viral integrase (IN). Whereas the fully active form of IN comprises a dimer of dimers, the molecular basis of IN multimerization has not been fully characterized. IN has consistently been crystallized in an analogous dimeric form in all crystallographic structures and experimental evidence as to the level of similarity between IN monomeric and dimeric conformations is missing because of the lack of IN monomeric structures. Here we identify Phe187 as a critical dimerization determinant of IN from feline immunodeficiency virus (FIV), a nonprimate lentivirus that causes AIDS in the natural host, and report, in addition to a canonical dimeric structure of the FIV IN core-domain, a monomeric structure revealing the preservation of the backbone structure between the two multimeric forms and suggest a role for Phe187 in "hinging" the flexible IN dimer.

  • Organizational Affiliation

    Faculty of Biology, Technion-Israel Institute of Technology, Haifa 320003, Israel. Electronic address: alian@tx.technion.ac.il.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Integrase151Feline immunodeficiency virus (isolate Petaluma)Mutation(s): 0
Gene Names: pol
EC: 3.4.23 (UniProt), (UniProt), (UniProt), (UniProt), (UniProt), 2.7.7 (UniProt), 3.1 (UniProt)
Find proteins for P16088 (Feline immunodeficiency virus (isolate Petaluma))
Explore P16088
Go to UniProtKB:  P16088
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP16088
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 1.84 Å
  • R-Value Free: 0.222
  • R-Value Work: 0.171
  • R-Value Observed: 0.174
  • Space Group: P 65 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 52.924α = 90
b = 52.924β = 90
c = 193.569γ = 120
Software Package:
Software NamePurpose
HKL-3000data scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-09-17
    Type: Initial release
  • Version 1.1: 2014-10-22
    Changes: Database references
