4P0G | pdb_00004p0g

Crystal structure of MltF from Pseudomonas aeruginosa complexed with bulgecin and muropeptide

PDB DOI: https://doi.org/10.2210/pdb4P0G/pdb

Classification: LYASE
Organism(s): Pseudomonas aeruginosa PAO1
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2014-02-21 Released: 2015-03-18
Deposition Author(s): Redden, E., Thunnissen, A.M.W.H.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.65 Å
R-Value Free:
0.187 (Depositor), 0.194 (DCC)
R-Value Work:
0.160 (Depositor), 0.173 (DCC)
R-Value Observed:
0.162 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 2.1 of the entry. See complete history.

Literature

Crystal structure of MltF from Pseudomonas aeruginosa complexed with bulgecin and muropeptide

Redden, E., Thunnissen, A.M.W.H.

To be published.

Macromolecule Content

Total Structure Weight: 50.51 kDa
Atom Count: 4,162
Modeled Residue Count: 429
Deposited Residue Count: 435
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Membrane-bound lytic murein transglycosylase F	A	435	Pseudomonas aeruginosa PAO1	Mutation(s): 0 Gene Names: mltF, PA3764 EC: 4.2.2
UniProt
Find proteins for Q9HXN1 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)) Explore Q9HXN1 Go to UniProtKB: Q9HXN1
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9HXN1
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-N-acetyl-beta-muramic acid	B	2		N/A	Interactions Focus chain B Interactions & Density Focus chain B
Glycosylation Resources
GlyTouCan: G99515FY GlyCosmos: G99515FY

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
BLG Query on BLG Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	4-O-(4-O-SULFONYL-N-ACETYLGLUCOSAMININYL)-5-METHYLHYDROXY-L-PROLINE-TAURINE C₁₆ H₃₀ N₃ O₁₄ S₂ RPNZWZDLNYCCIG-HMMVDTEZSA-O		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A]	G [auth A], H [auth A], I [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Interactions & Density Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A]	D [auth A], E [auth A], F [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.65 Å
R-Value Free: 0.187 (Depositor), 0.194 (DCC)
R-Value Work: 0.160 (Depositor), 0.173 (DCC)
R-Value Observed: 0.162 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 58.325	α = 90
b = 82.239	β = 90
c = 95.207	γ = 90

Software Package:

Software Name	Purpose
MOSFLM	data reduction
SCALA	data scaling
WARP	model building
PHENIX	refinement
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2015-03-18

Deposition Author(s):

Redden, E.

Thunnissen, A.M.W.H.

Revision History (Full details and data files)

Version 1.0: 2015-03-18
Type: Initial release
Version 1.1: 2017-09-27
Changes: Derived calculations, Refinement description, Source and taxonomy
Version 1.2: 2017-11-01
Changes: Author supporting evidence
Version 2.0: 2020-07-29
Type: Remediation
Reason: Carbohydrate remediation
Changes: Atomic model, Data collection, Derived calculations, Structure summary
Version 2.1: 2023-12-27
Changes: Data collection, Database references, Derived calculations, Structure summary
