4OFE | pdb_00004ofe

Structural basis for thymine glycosylase activity on T:O6-methylG mismatch by methyl-CpG binding domain protein 4: Implications for roles of Arg468 in mismatch recognition and catalysis

PDB DOI: https://doi.org/10.2210/pdb4OFE/pdb
NAKB: 4OFE

Classification: HYDROLASE/DNA
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21
Mutation(s): Yes

Deposited: 2014-01-14 Released: 2015-04-22
Deposition Author(s): Ouzon-Shubeita, H., Lin, Y.-L., Lee, S.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.15 Å
R-Value Free:
0.202 (Depositor), 0.202 (DCC)
R-Value Work:
0.142 (Depositor), 0.150 (DCC)
R-Value Observed:
0.145 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 4OFE

This is version 1.1 of the entry. See complete history.

Literature

Structure of R468K/D560N MBD4 bound to G:T mispair DNA

Ouzon-Shubeita, H., Lin, Y.-L., Lee, S.

To be published.

Macromolecule Content

Total Structure Weight: 29.83 kDa
Atom Count: 1,829
Modeled Residue Count: 166
Deposited Residue Count: 216
Unique protein chains: 1
Unique nucleic acid chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Methyl-CpG-binding domain protein 4	A	192	Homo sapiens	Mutation(s): 2 Gene Names: MBD4, MED1 EC: 3.2.2
UniProt & NIH Common Fund Data Resources
Find proteins for O95243 (Homo sapiens) Explore O95243 Go to UniProtKB: O95243
PHAROS: O95243 GTEx: ENSG00000129071
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O95243
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence

Molecule	Chains	Length	Organism	Image
Entity ID: 2
12-mer DNA(T)	B [auth C]	12	N/A
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence

Molecule	Chains	Length	Organism	Image
Entity ID: 3
12-mer DNA(G)	C [auth D]	12	N/A
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.15 Å
R-Value Free: 0.202 (Depositor), 0.202 (DCC)
R-Value Work: 0.142 (Depositor), 0.150 (DCC)
R-Value Observed: 0.145 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 41.722	α = 90
b = 55.605	β = 90
c = 104.245	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data collection
MOLREP	phasing
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2015-04-22

Deposition Author(s):

Ouzon-Shubeita, H.

Revision History (Full details and data files)

Version 1.0: 2015-04-22
Type: Initial release
Version 1.1: 2023-09-20
Changes: Data collection, Database references, Derived calculations, Refinement description
