4NHE | pdb_00004nhe

The crystal structure of oxidoreductase (Gfo/Idh/MocA family) from Streptococcus pneumoniae TIGR4 in complex with NADP

PDB DOI: https://doi.org/10.2210/pdb4NHE/pdb

Classification: OXIDOREDUCTASE
Organism(s): Streptococcus pneumoniae TIGR4
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2013-11-04 Released: 2013-11-27
Deposition Author(s): Tan, K., Hatzos-Skintges, C., Jedrzejczak, R., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.95 Å
R-Value Free:
0.207 (Depositor), 0.210 (DCC)
R-Value Work:
0.176 (Depositor), 0.180 (DCC)
R-Value Observed:
0.177 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

The crystal structure of oxidoreductase (Gfo/Idh/MocA family) from Streptococcus pneumoniae TIGR4 in complex with NADP.

Tan, K., Hatzos-Skintges, C., Jedrzejczak, R., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 113.21 kDa
Atom Count: 8,491
Modeled Residue Count: 977
Deposited Residue Count: 984
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Oxidoreductase, Gfo/Idh/MocA family	A, B, C	328	Streptococcus pneumoniae TIGR4	Mutation(s): 0 Gene Names: SP_1482
UniProt
Find proteins for A0A0H2UR04 (Streptococcus pneumoniae serotype 4 (strain ATCC BAA-334 / TIGR4)) Explore A0A0H2UR04 Go to UniProtKB: A0A0H2UR04
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A0H2UR04
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAP Query on NAP Download Ideal Coordinates CCD File SDF format, chain N [auth C] SDF format, chain H [auth B] SDF format, chain D [auth A] MOL2 format, chain N [auth C] MOL2 format, chain H [auth B] MOL2 format, chain D [auth A] mmCIF format, chain N [auth C] mmCIF format, chain H [auth B] mmCIF format, chain D [auth A]	D [auth A], H [auth B], N [auth C]	NADP NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE C₂₁ H₂₈ N₇ O₁₇ P₃ XJLXINKUBYWONI-NNYOXOHSSA-N		Interactions Focus chain D [auth A] Focus chain H [auth B] Focus chain N [auth C] Interactions & Density Focus chain D [auth A] Focus chain H [auth B] Focus chain N [auth C]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain V [auth C] SDF format, chain U [auth C] SDF format, chain M [auth B] MOL2 format, chain V [auth C] MOL2 format, chain U [auth C] MOL2 format, chain M [auth B] mmCIF format, chain V [auth C] mmCIF format, chain U [auth C] mmCIF format, chain M [auth B]	M [auth B], U [auth C], V [auth C]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain M [auth B] Focus chain U [auth C] Focus chain V [auth C] Interactions & Density Focus chain M [auth B] Focus chain U [auth C] Focus chain V [auth C]
ACT Query on ACT Download Ideal Coordinates CCD File SDF format, chain W [auth C] MOL2 format, chain W [auth C] mmCIF format, chain W [auth C]	W [auth C]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain W [auth C] Interactions & Density Focus chain W [auth C]
FMT Query on FMT Download Ideal Coordinates CCD File SDF format, chain T [auth C] SDF format, chain S [auth C] SDF format, chain R [auth C] SDF format, chain Q [auth C] SDF format, chain P [auth C] SDF format, chain O [auth C] SDF format, chain L [auth B] SDF format, chain K [auth B] SDF format, chain J [auth B] SDF format, chain I [auth B] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] MOL2 format, chain T [auth C] MOL2 format, chain S [auth C] MOL2 format, chain R [auth C] MOL2 format, chain Q [auth C] MOL2 format, chain P [auth C] MOL2 format, chain O [auth C] MOL2 format, chain L [auth B] MOL2 format, chain K [auth B] MOL2 format, chain J [auth B] MOL2 format, chain I [auth B] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] mmCIF format, chain T [auth C] mmCIF format, chain S [auth C] mmCIF format, chain R [auth C] mmCIF format, chain Q [auth C] mmCIF format, chain P [auth C] mmCIF format, chain O [auth C] mmCIF format, chain L [auth B] mmCIF format, chain K [auth B] mmCIF format, chain J [auth B] mmCIF format, chain I [auth B] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A]	E [auth A] F [auth A] G [auth A] I [auth B] J [auth B] E [auth A], F [auth A], G [auth A], I [auth B], J [auth B], K [auth B], L [auth B], O [auth C], P [auth C], Q [auth C], R [auth C], S [auth C], T [auth C]	FORMIC ACID C H₂ O₂ BDAGIHXWWSANSR-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain O [auth C] Focus chain P [auth C] Focus chain Q [auth C] Focus chain R [auth C] Focus chain S [auth C] Focus chain T [auth C] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain O [auth C] Focus chain P [auth C] Focus chain Q [auth C] Focus chain R [auth C] Focus chain S [auth C] Focus chain T [auth C]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.95 Å
R-Value Free: 0.207 (Depositor), 0.210 (DCC)
R-Value Work: 0.176 (Depositor), 0.180 (DCC)
R-Value Observed: 0.177 (Depositor)

Space Group: F 2 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 97.768	α = 90
b = 195.905	β = 90
c = 349.301	γ = 90

Software Package:

Software Name	Purpose
SBC-Collect	data collection
MOLREP	phasing
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2013-11-27

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Revision History (Full details and data files)

Version 1.0: 2013-11-27
Type: Initial release
Version 1.1: 2023-09-20
Changes: Data collection, Database references, Derived calculations, Refinement description
