4NEJ | pdb_00004nej

Small molecular fragment bound to crystal contact interface of Interleukin-2

• PDB DOI: https://doi.org/10.2210/pdb4NEJ/pdb

• Classification: IMMUNE SYSTEM
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2013-10-29 Released: 2014-11-19
• Deposition Author(s): Brenke, R., Jehle, S., Vajda, S., Allen, K.N., Kozakov, D.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.92 Å
• R-Value Free:
  0.258 (Depositor), 0.260 (DCC)
• R-Value Work:
  0.208 (Depositor), 0.210 (DCC)
• R-Value Observed:
  0.211 (Depositor)

Literature

Small molecular fragments bound to binding energy hot-spot in crystal contact interface of Interleukin-2

Brenke, R., Jehle, S., Vajda, S., Allen, K.N., Kozakov, D.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 15.4 kDa
• Atom Count: 1,047
• Modeled Residue Count: 118
• Deposited Residue Count: 130
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Interleukin-2	A	130	Homo sapiens	Mutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P60568 (Homo sapiens) Explore P60568  Go to UniProtKB:  P60568
PHAROS:  P60568 GTEx:  ENSG00000109471

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
2K1	B [auth A], C [auth A]	5-methylfuran-2-carboxylic acid C6 H6 O3 OVOCLWJUABOAPL-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.92 Å
• R-Value Free:  0.258 (Depositor), 0.260 (DCC)
• R-Value Work:  0.208 (Depositor), 0.210 (DCC)
• R-Value Observed: 0.211 (Depositor)

Space Group: P 2₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 48.069	α = 90
b = 86.626	β = 90
c = 32.137	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data collection
PHENIX	model building
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHENIX	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2014-11-19
Deposition Author(s): Brenke, R., Jehle, S., Vajda, S., Allen, K.N., Kozakov, D.

Revision History

• Version 1.0: 2014-11-19
  Type: Initial release

• Version 1.1: 2024-11-20
  Changes: Data collection, Database references, Derived calculations, Structure summary
