4N1P | pdb_00004n1p

Structure of Cyclophilin A in complex with Picolinamide.

• PDB DOI: https://doi.org/10.2210/pdb4N1P/pdb

• Classification: ISOMERASE
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2013-10-04 Released: 2015-08-12
• Deposition Author(s): Mcnae, I.W., Dornan, J., Walkinshaw, M.D.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.90 Å
• R-Value Free:
  0.258 (Depositor), 0.262 (DCC)
• R-Value Work:
  0.197 (Depositor), 0.204 (DCC)
• R-Value Observed:
  0.200 (Depositor)

Literature

Mapping the binding surface of Cyclophilin A.

Mcnae, I.W., Dornan, D., Patterson, A.F., Wear, M.A., Blackburn, E.A., Walkinshaw, M.D.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 18.4 kDa
• Atom Count: 1,517
• Modeled Residue Count: 165
• Deposited Residue Count: 165
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Peptidyl-prolyl cis-trans isomerase A	A	165	Homo sapiens	Mutation(s): 0  Gene Names: PPIA, CYPA EC: 5.2.1.8
UniProt & NIH Common Fund Data Resources
Find proteins for P62937 (Homo sapiens) Explore P62937  Go to UniProtKB:  P62937
PHAROS:  P62937 GTEx:  ENSG00000196262

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
WM1	B [auth A], C [auth A], D [auth A]	pyridine-2-carboxamide C6 H6 N2 O IBBMAWULFFBRKK-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.90 Å
• R-Value Free:  0.258 (Depositor), 0.262 (DCC)
• R-Value Work:  0.197 (Depositor), 0.204 (DCC)
• R-Value Observed: 0.200 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 42.81	α = 90
b = 54.28	β = 90
c = 87.14	γ = 90

Software Package:

Software Name	Purpose
MAR345dtb	data collection
PHASER	phasing
REFMAC	refinement
MOSFLM	data reduction
SCALA	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2015-08-12
Deposition Author(s): Mcnae, I.W., Dornan, J., Walkinshaw, M.D.

Revision History

• Version 1.0: 2015-08-12
  Type: Initial release

• Version 1.1: 2024-02-28
  Changes: Data collection, Database references, Derived calculations, Structure summary
