4MRP | pdb_00004mrp

Structure of a bacterial Atm1-family ABC transporter


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free:
    0.231 (Depositor), 0.235 (DCC)
  • R-Value Work:
    0.202 (Depositor), 0.205 (DCC)
  • R-Value Observed:
    0.203 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4MRP

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

Structural basis for heavy metal detoxification by an Atm1-type ABC exporter.

Lee, J.Y.Yang, J.G.Zhitnitsky, D.Lewinson, O.Rees, D.C.

(2014) Science 343: 1133-1136

  • DOI: https://doi.org/10.1126/science.1246489
  • Primary Citation Related Structures:
    4MRN, 4MRP, 4MRR, 4MRS, 4MRV

  • PubMed Abstract:

    Although substantial progress has been achieved in the structural analysis of exporters from the superfamily of adenosine triphosphate (ATP)-binding cassette (ABC) transporters, much less is known about how they selectively recognize substrates and how substrate binding is coupled to ATP hydrolysis. We have addressed these questions through crystallographic analysis of the Atm1/ABCB7/HMT1/ABCB6 ortholog from Novosphingobium aromaticivorans DSM 12444, NaAtm1, at 2.4 angstrom resolution. Consistent with a physiological role in cellular detoxification processes, functional studies showed that glutathione derivatives can serve as substrates for NaAtm1 and that its overexpression in Escherichia coli confers protection against silver and mercury toxicity. The glutathione binding site highlights the articulated design of ABC exporters, with ligands and nucleotides spanning structurally conserved elements to create adaptable interfaces accommodating conformational rearrangements during the transport cycle.


  • Organizational Affiliation
    • Howard Hughes Medical Institute and Division of Chemistry and Chemical Engineering, Mail Code 114-96, California Institute of Technology, Pasadena, CA 91125, USA.

Macromolecule Content

  • Total Structure Weight: 138.67 kDa
  • Atom Count: 9,673
  • Modeled Residue Count: 1,198
  • Deposited Residue Count: 1,228
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
ABC transporter related protein
A, B
614Novosphingobium aromaticivorans DSM 12444Mutation(s): 0
Gene Names: ATM1Saro_2631
EC: 7
Membrane Entity: Yes
UniProt
Find proteins for Q2G506 (Novosphingobium aromaticivorans (strain ATCC 700278 / DSM 12444 / CCUG 56034 / CIP 105152 / NBRC 16084 / F199))
Explore Q2G506
Go to UniProtKB:  Q2G506
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ2G506
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
GSH

Query on GSH



Download:Ideal Coordinates CCD File
E [auth A],
J [auth B]
Glutathione
C10 H17 N3 O6 S
RWSXRVCMGQZWBV-WDSKDSINSA-N
LDA

Query on LDA



Download:Ideal Coordinates CCD File
C [auth A],
D [auth A],
H [auth B],
I [auth B]
LAURYL DIMETHYLAMINE-N-OXIDE
C14 H31 N O
SYELZBGXAIXKHU-UHFFFAOYSA-N
PO4

Query on PO4



Download:Ideal Coordinates CCD File
F [auth A],
G [auth A],
K [auth B],
L [auth B]
PHOSPHATE ION
O4 P
NBIIXXVUZAFLBC-UHFFFAOYSA-K
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A, B
L-PEPTIDE LINKINGC5 H11 N O2 SeMET

Biologically Interesting Molecules (External Reference)

1 Unique

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free:  0.231 (Depositor), 0.235 (DCC)
  • R-Value Work:  0.202 (Depositor), 0.205 (DCC)
  • R-Value Observed: 0.203 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 321.853α = 90
b = 95.262β = 102.01
c = 79.01γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
REFMACrefinement
Blu-Icedata collection
XDSdata reduction
Aimlessdata scaling
REFMACphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-03-19
    Type: Initial release
  • Version 1.1: 2019-07-17
    Changes: Data collection, Derived calculations, Refinement description
  • Version 1.2: 2025-03-26
    Changes: Data collection, Database references, Derived calculations, Structure summary
