Biological Assembly 1

 3D View: Structure | Electron Density | Ligand Interaction

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 53.58 kDa
• Atom Count: 3034
• Modelled Residue Count: 398
• Deposited Residue Count: 476
• Unique protein chains: 2

4MQS

Structure of active human M2 muscarinic acetylcholine receptor bound to the agonist iperoxo

• DOI: 10.2210/pdb4MQS/pdb

• Classification: SIGNALING PROTEIN
• Organism(s): Homo sapiens, Lama glama
• Expression System: Spodoptera frugiperda, Escherichia coli BL21(DE3)
• Mutation(s): Yes


• Deposited: 2013-09-16 Released: 2013-11-27
• Deposition Author(s): Kruse, A.C., Ring, A.M., Manglik, A., Hu, J., Hu, K., Eitel, K., Huebner, H., Pardon, E., Valant, C., Sexton, P.M., Christopoulos, A., Felder, C.C., Gmeiner, P., Steyaert, J., Weis, W.I., Garcia, K.C., Wess, J., Kobilka, B.K.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 3.50 Å
• R-Value Free: 0.298
• R-Value Work: 0.249
• R-Value Observed: 0.254

Literature

Activation and allosteric modulation of a muscarinic acetylcholine receptor.

Kruse, A.C., Ring, A.M., Manglik, A., Hu, J., Hu, K., Eitel, K., Hubner, H., Pardon, E., Valant, C., Sexton, P.M., Christopoulos, A., Felder, C.C., Gmeiner, P., Steyaert, J., Weis, W.I., Garcia, K.C., Wess, J., Kobilka, B.K.

(2013) Nature 504: 101-106

• PubMed: 24256733
• DOI: 10.1038/nature12735
• Primary Citation of Related Structures:
  4MQS, 4MQT


• PubMed Abstract:


Despite recent advances in crystallography and the availability of G-protein-coupled receptor (GPCR) structures, little is known about the mechanism of their activation process, as only the β2 adrenergic receptor (β2AR) and rhodopsin have been crystallized in fully active conformations. Here we report the structure of an agonist-bound, active state of the human M2 muscarinic acetylcholine receptor stabilized by a G-protein mimetic camelid antibody fragment isolated by conformational selection using yeast surface display. In addition to the expected changes in the intracellular surface, the structure reveals larger conformational changes in the extracellular region and orthosteric binding site than observed in the active states of the β2AR and rhodopsin. We also report the structure of the M2 receptor simultaneously bound to the orthosteric agonist iperoxo and the positive allosteric modulator LY2119620. This structure reveals that LY2119620 recognizes a largely pre-formed binding site in the extracellular vestibule of the iperoxo-bound receptor, inducing a slight contraction of this outer binding pocket. These structures offer important insights into the activation mechanism and allosteric modulation of muscarinic receptors.

---

Organizational Affiliation:

1] Department of Molecular and Cellular Physiology, Stanford University School of Medicine, 279 Campus Drive, Stanford, California 94305, USA [2].

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Muscarinic acetylcholine receptor M2	A	351	Homo sapiens	Mutation(s): 6  Gene Names: CHRM2
Membrane protein Mpstruc	Group:  TRANSMEMBRANE PROTEINS: ALPHA-HELICAL		Sub Group:  G Protein-Coupled Receptors: Class A	Protein:  M2 muscarinic acetylcholine receptor bound to the agonist iperoxo
Find proteins for P08172 (Homo sapiens) Explore P08172  Go to UniProtKB:  P08172
NIH Common Fund Data Resources
PHAROS:  P08172 GTEx:  ENSG00000181072

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Nanobody 9-8	B	125	Lama glama	Mutation(s): 0

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
IXO	C [auth A]	4-(4,5-dihydro-1,2-oxazol-3-yloxy)-N,N,N-trimethylbut-2-yn-1-aminium C10 H17 N2 O2 WXXOCGISBCTWPW-UHFFFAOYSA-N

External Ligand Annotations
ID	Binding Affinity (Sequence Identity %)
IXO	Ki:  2.5   nM  BindingDB
IXO	Ki:  10   nM  BindingDB
IXO	EC50:  0.17000000178813934   nM  BindingDB
IXO	Ki:  257   nM  BindingDB
IXO	Ki:  2.200000047683716   nM  BindingDB
IXO	Ki:  4.900000095367432   nM  BindingDB
IXO	EC50:  0.07999999821186066   nM  BindingDB
IXO	EC50:  0.2800000011920929   nM  BindingDB
IXO	Ki:  8.699999809265137   nM  BindingDB

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 3.50 Å
• R-Value Free: 0.298
• R-Value Work: 0.249
• R-Value Observed: 0.254
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 62.896	α = 90
b = 78.13	β = 90
c = 163.482	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data collection
PHASER	phasing
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

Entry History

Deposition Data

• Deposited Date: 2013-09-16
• Released Date: 2013-11-27
Deposition Author(s): Kruse, A.C., Ring, A.M., Manglik, A., Hu, J., Hu, K., Eitel, K., Huebner, H., Pardon, E., Valant, C., Sexton, P.M., Christopoulos, A., Felder, C.C., Gmeiner, P., Steyaert, J., Weis, W.I., Garcia, K.C., Wess, J., Kobilka, B.K.

Revision History

• Version 1.0: 2013-11-27
  Type: Initial release

• Version 1.1: 2013-12-04
  Changes: Database references
• Version 1.2: 2013-12-18
  Changes: Database references
• Version 1.3: 2017-07-05
  Changes: Source and taxonomy
