4M3L | pdb_00004m3l

Crystal Structure of the coiled coil domain of MuRF1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free:
    0.262 (Depositor), 0.261 (DCC)
  • R-Value Work:
    0.212 (Depositor), 0.212 (DCC)
  • R-Value Observed:
    0.214 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4M3L

This is version 1.2 of the entry. See complete history

Literature

Molecular basis for the fold organization and sarcomeric targeting of the muscle atrogin MuRF1.

Franke, B.Gasch, A.Rodriguez, D.Chami, M.Khan, M.M.Rudolf, R.Bibby, J.Hanashima, A.Bogomolovas, J.von Castelmur, E.Rigden, D.J.Uson, I.Labeit, S.Mayans, O.

(2014) Open Biol 4: 130172-130172

  • DOI: https://doi.org/10.1098/rsob.130172
  • Primary Citation Related Structures:
    4M3L

  • PubMed Abstract:

    MuRF1 is an E3 ubiquitin ligase central to muscle catabolism. It belongs to the TRIM protein family characterized by a tripartite fold of RING, B-box and coiled-coil (CC) motifs, followed by variable C-terminal domains. The CC motif is hypothesized to be responsible for domain organization in the fold as well as for high-order assembly into functional entities. But data on CC from this family that can clarify the structural significance of this motif are scarce. We have characterized the helical region from MuRF1 and show that, contrary to expectations, its CC domain assembles unproductively, being the B2- and COS-boxes in the fold (respectively flanking the CC) that promote a native quaternary structure. In particular, the C-terminal COS-box seemingly forms an α-hairpin that packs against the CC, influencing its dimerization. This shows that a C-terminal variable domain can be tightly integrated within the conserved TRIM fold to modulate its structure and function. Furthermore, data from transfected muscle show that in MuRF1 the COS-box mediates the in vivo targeting of sarcoskeletal structures and points to the pharmacological relevance of the COS domain for treating MuRF1-mediated muscle atrophy.


  • Organizational Affiliation
    • Institute of Integrative Biology, University of Liverpool, Biosciences Building, Crown Street, Liverpool L69 7ZB, UK.

Macromolecule Content

  • Total Structure Weight: 29.68 kDa
  • Atom Count: 2,021
  • Modeled Residue Count: 228
  • Deposited Residue Count: 244
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
E3 ubiquitin-protein ligase TRIM63A,
B [auth C],
C [auth B],
D
61Homo sapiensMutation(s): 1
Gene Names: IRFMURF1RNF28SMRZTRIM63
EC: 6.3.2 (PDB Primary Data), 2.3.2.27 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for Q969Q1 (Homo sapiens)
Explore Q969Q1
Go to UniProtKB:  Q969Q1
PHAROS:  Q969Q1
GTEx:  ENSG00000158022
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ969Q1
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MPD

Query on MPD



Download:Ideal Coordinates CCD File
E [auth A](4S)-2-METHYL-2,4-PENTANEDIOL
C6 H14 O2
SVTBMSDMJJWYQN-YFKPBYRVSA-N
GOL

Query on GOL



Download:Ideal Coordinates CCD File
F [auth A]
G [auth A]
J [auth C]
K [auth C]
M [auth C]
F [auth A],
G [auth A],
J [auth C],
K [auth C],
M [auth C],
N [auth C],
Q [auth B],
R [auth B],
S [auth B],
V [auth B],
X [auth D]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
ACT

Query on ACT



Download:Ideal Coordinates CCD File
H [auth A]
I [auth A]
L [auth C]
O [auth C]
P [auth C]
H [auth A],
I [auth A],
L [auth C],
O [auth C],
P [auth C],
T [auth B],
U [auth B],
W [auth B],
Y [auth D]
ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free:  0.262 (Depositor), 0.261 (DCC)
  • R-Value Work:  0.212 (Depositor), 0.212 (DCC)
  • R-Value Observed: 0.214 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 70.79α = 90
b = 24.41β = 107.65
c = 75.39γ = 90
Software Package:
Software NamePurpose
Arcimboldophasing
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-03-26
    Type: Initial release
  • Version 1.1: 2018-10-10
    Changes: Data collection, Database references, Structure summary
  • Version 1.2: 2024-02-28
    Changes: Data collection, Database references, Derived calculations, Structure summary
