4LXR

Structure of the Toll - Spatzle complex, a molecular hub in Drosophila development and innate immunity


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.218
  • R-Value Work: 0.176
  • R-Value Observed: 0.178

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 2.0 of the entry. See complete history


Literature

Structure of the Toll-Spatzle complex, a molecular hub in Drosophila development and innate immunity.

Parthier, C.Stelter, M.Ursel, C.Fandrich, U.Lilie, H.Breithaupt, C.Stubbs, M.T.

(2014) Proc Natl Acad Sci U S A 111: 6281-6286

  • DOI: 10.1073/pnas.1320678111
  • Primary Citation of Related Structures:
    4LXR, 4LXS

  • PubMed Abstract:
  • Drosophila Toll receptors are involved in embryonic development and the immune response of adult flies. In both processes, the only known Toll receptor ligand is the human nerve growth factor-like cystine knot protein Spätzle. Here we present the crystal structure of a 1:1 (nonsignaling) complex of the full-length Toll receptor ectodomain (ECD) with the Spätzle cystine knot domain dimer ...

    Drosophila Toll receptors are involved in embryonic development and the immune response of adult flies. In both processes, the only known Toll receptor ligand is the human nerve growth factor-like cystine knot protein Spätzle. Here we present the crystal structure of a 1:1 (nonsignaling) complex of the full-length Toll receptor ectodomain (ECD) with the Spätzle cystine knot domain dimer. The ECD is divided into two leucine-rich repeat (LRR) domains, each of which is capped by cysteine-rich domains. Spätzle binds to the concave surface of the membrane-distal LRR domain, in contrast to the flanking ligand interactions observed for mammalian Toll-like receptors, with asymmetric contributions from each Spätzle protomer. The structure allows rationalization of existing genetic and biochemical data and provides a framework for targeting the immune systems of insects of economic importance, as well as a variety of invertebrate disease vectors.


    Organizational Affiliation

    Institut für Biochemie und Biotechnologie and Mitteldeutsches Zentrum für Struktur und Dynamik von Proteinen, Martin-Luther-Universität Halle-Wittenberg, 06120 Halle (Saale), Germany.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Protein tollA783Drosophila melanogasterMutation(s): 0
Gene Names: TlCG5490
EC: 3.2.2.6
UniProt
Find proteins for P08953 (Drosophila melanogaster)
Explore P08953
Go to UniProtKB:  P08953
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Protein spaetzle C-106B [auth J], C [auth K]114Drosophila melanogasterMutation(s): 0
Gene Names: spzCG6134
UniProt
Find proteins for P48607 (Drosophila melanogaster)
Explore P48607
Go to UniProtKB:  P48607
Protein Feature View
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 3
MoleculeChainsChain Length2D DiagramGlycosylation3D Interactions
alpha-D-mannopyranose-(1-3)-beta-D-mannopyranose-(1-3)-beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranoseD [auth B]5N-Glycosylation Oligosaccharides Interaction
Glycosylation Resources
GlyTouCan:  G52322TF
GlyCosmos:  G52322TF
GlyGen:  G52322TF
Entity ID: 4
MoleculeChainsChain Length2D DiagramGlycosylation3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranoseE [auth C], G [auth E]2N-Glycosylation Oligosaccharides Interaction
Glycosylation Resources
GlyTouCan:  G42666HT
GlyCosmos:  G42666HT
GlyGen:  G42666HT
Entity ID: 5
MoleculeChainsChain Length2D DiagramGlycosylation3D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranoseF [auth D]3N-Glycosylation Oligosaccharides Interaction
Glycosylation Resources
GlyTouCan:  G15407YE
GlyCosmos:  G15407YE
GlyGen:  G15407YE
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
EPE
Query on EPE

Download Ideal Coordinates CCD File
N [auth A]4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID
C8 H18 N2 O4 S
JKMHFZQWWAIEOD-UHFFFAOYSA-N
 Ligand Interaction
NAG (Subject of Investigation/LOI)
Query on NAG

Download Ideal Coordinates CCD File
H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A]2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.218
  • R-Value Work: 0.176
  • R-Value Observed: 0.178
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 172.025α = 90
b = 78.175β = 126.3
c = 124.45γ = 90
Software Package:
Software NamePurpose
XSCALEdata scaling
SOLOMONphasing
PHENIXrefinement
PDB_EXTRACTdata extraction
MAR345data collection
XDSdata reduction
XDSdata scaling
SHARPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-04-09
    Type: Initial release
  • Version 1.1: 2014-05-21
    Changes: Database references
  • Version 1.2: 2017-11-15
    Changes: Refinement description
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Database references, Derived calculations, Structure summary
