4LLE | pdb_00004lle

The crystal structure of R60L mutant of the histidine kinase (KinB) sensor domain from Pseudomonas aeruginosa PA01

• PDB DOI: https://doi.org/10.2210/pdb4LLE/pdb

• Classification: TRANSFERASE
• Organism(s): Pseudomonas aeruginosa PAO1
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): Yes


• Deposited: 2013-07-09 Released: 2013-08-07
• Deposition Author(s): Tan, K., Chhor, G., Jedrzejczak, R., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.68 Å
• R-Value Free:
  0.242 (Depositor), 0.238 (DCC)
• R-Value Work:
  0.196 (Depositor), 0.195 (DCC)
• R-Value Observed:
  0.198 (Depositor)

Starting Model: experimental

Literature

The crystal structure of R60L mutant of the histidine kinase (KinB) sensor domain from Pseudomonas aeruginosa PA01

Tan, K., Chhor, G., Jedrzejczak, R., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 58.42 kDa
• Atom Count: 3,974
• Modeled Residue Count: 466
• Deposited Residue Count: 520
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Probable two-component sensor	A, B, C, D	130	Pseudomonas aeruginosa PAO1	Mutation(s): 1  Gene Names: PA5484 EC: 2.7.13.3
UniProt
Find proteins for Q9HT87 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)) Explore Q9HT87  Go to UniProtKB:  Q9HT87

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GOL	E [auth A], F [auth B], G [auth B], H [auth C]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B, C, D	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.68 Å
• R-Value Free:  0.242 (Depositor), 0.238 (DCC)
• R-Value Work:  0.196 (Depositor), 0.195 (DCC)
• R-Value Observed: 0.198 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 45.235	α = 75.98
b = 47.804	β = 80.19
c = 49.422	γ = 74.54

Software Package:

Software Name	Purpose
SBC-Collect	data collection
MOLREP	phasing
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2013-08-07
Deposition Author(s): Tan, K., Chhor, G., Jedrzejczak, R., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2013-08-07
  Type: Initial release

• Version 1.1: 2013-08-14
  Changes: Other
• Version 1.2: 2023-09-20
  Changes: Data collection, Database references, Derived calculations, Refinement description
• Version 1.3: 2023-12-06
  Changes: Data collection
• Version 1.4: 2024-11-20
  Changes: Structure summary
