4KP4

Deciphering cis-trans directionality and visualizing autophosphorylation in histidine kinases.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3 Å
  • R-Value Free: 0.234
  • R-Value Work: 0.194

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

Visualizing autophosphorylation in histidine kinases.

Casino, P.Miguel-Romero, L.Marina, A.

(2014) Nat Commun 5: 3258-3258

  • DOI: 10.1038/ncomms4258

  • PubMed Abstract:
  • Reversible protein phosphorylation is the most widespread regulatory mechanism in signal transduction. Autophosphorylation in a dimeric sensor histidine kinase is the first step in two-component signalling, the predominant signal-transduction device ...

    Reversible protein phosphorylation is the most widespread regulatory mechanism in signal transduction. Autophosphorylation in a dimeric sensor histidine kinase is the first step in two-component signalling, the predominant signal-transduction device in bacteria. Despite being the most abundant sensor kinases in nature, the molecular bases of the histidine kinase autophosphorylation mechanism are still unknown. Furthermore, it has been demonstrated that autophosphorylation can occur in two directions, cis (intrasubunit) or trans (intersubunit) within the dimeric histidine kinase. Here, we present the crystal structure of the complete catalytic machinery of a chimeric histidine kinase. The structure shows an asymmetric histidine kinase dimer where one subunit is caught performing the autophosphorylation reaction. A structure-guided functional analysis on HK853 and EnvZ, two prototypical cis- and trans-phosphorylating histidine kinases, has allowed us to decipher the catalytic mechanism of histidine kinase autophosphorylation, which seems to be common independently of the reaction directionality.


    Organizational Affiliation

    1] Department of Genomic and Proteomic, Instituto de Biomedicina de Valencia (IBV-CSIC), Jaume Roig 11, 46010 Valencia, Spain [2] Department of Structural Biology, Institut de BiologĂ­a Molecular de Barcelona (IBMB-CSIC), Baldiri Reixac, 4-8, Torre R, 3era Planta, 08028 Barcelona, Spain.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Osmolarity sensor protein EnvZ, Histidine kinase
A, B
236Escherichia coli (strain K12)Thermotoga maritima (strain ATCC 43589 / MSB8 / DSM 3109 / JCM 10099)
This entity is chimeric
Mutation(s): 0
Gene Names: envZ (ompB, perA, tpo),
EC: 2.7.13.3
Find proteins for P0AEJ4 (Escherichia coli (strain K12))
Go to UniProtKB:  P0AEJ4
Find proteins for Q9WZV7 (Thermotoga maritima (strain ATCC 43589 / MSB8 / DSM 3109 / JCM 10099))
Go to UniProtKB:  Q9WZV7
Small Molecules
Ligands 4 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A, B
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
ANP
Query on ANP

Download SDF File
Download CCD File
A
PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER
C10 H17 N6 O12 P3
PVKSNHVPLWYQGJ-KQYNXXCUSA-N
 Ligand Interaction
MG
Query on MG

Download SDF File
Download CCD File
A
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
PEG
Query on PEG

Download SDF File
Download CCD File
A
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3 Å
  • R-Value Free: 0.234
  • R-Value Work: 0.194
  • Space Group: P 65 2 2
Unit Cell:
Length (Å)Angle (°)
a = 163.686α = 90.00
b = 163.686β = 90.00
c = 130.093γ = 120.00
Software Package:
Software NamePurpose
SCALAdata scaling
PHASERphasing
REFMACrefinement
XDSdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2014-02-12
    Type: Initial release
  • Version 1.1: 2014-02-19
    Type: Database references
  • Version 1.2: 2017-08-16
    Type: Refinement description, Source and taxonomy
  • Version 1.3: 2017-11-15
    Type: Refinement description
