4K46 | pdb_00004k46

Crystal Structure of Adenylate Kinase from Photobacterium profundum

PDB DOI: https://doi.org/10.2210/pdb4K46/pdb

Classification: TRANSFERASE
Organism(s): Photobacterium profundum
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2013-04-12 Released: 2014-07-16
Deposition Author(s): Cho, Y.-J., Kerns, S.J., Kern, D.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.01 Å
R-Value Free:
0.223 (Depositor), 0.221 (DCC)
R-Value Work:
0.167 (Depositor), 0.168 (DCC)
R-Value Observed:
0.170 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4K46

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Alike but Different: Adenylate kinases from E. Coli, Aquifex, and P. profundum

Cho, Y.-J., Kerns, S.J., Kern, D.

To be published.

Macromolecule Content

Total Structure Weight: 23.9 kDa
Atom Count: 1,915
Modeled Residue Count: 214
Deposited Residue Count: 214
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Adenylate kinase	A	214	Photobacterium profundum	Mutation(s): 0 Gene Names: adk, PBPRA1024 EC: 2.7.4.3
UniProt
Find proteins for Q6LTE1 (Photobacterium profundum (strain SS9)) Explore Q6LTE1 Go to UniProtKB: Q6LTE1
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q6LTE1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ADP Query on ADP Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	ADENOSINE-5'-DIPHOSPHATE C₁₀ H₁₅ N₅ O₁₀ P₂ XTWYTFMLZFPYCI-KQYNXXCUSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
AMP Query on AMP Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	ADENOSINE MONOPHOSPHATE C₁₀ H₁₄ N₅ O₇ P UDMBCSSLTHHNCD-KQYNXXCUSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
PO4 Query on PO4 Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.01 Å
R-Value Free: 0.223 (Depositor), 0.221 (DCC)
R-Value Work: 0.167 (Depositor), 0.168 (DCC)
R-Value Observed: 0.170 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 42.59	α = 90
b = 70.23	β = 90
c = 71.68	γ = 90

Software Package:

Software Name	Purpose
MOSFLM	data reduction
SCALA	data scaling
PHASER	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2014-07-16

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2014-07-16
Type: Initial release
Version 1.1: 2024-02-28
Changes: Data collection, Database references, Derived calculations
