4JP7

High resolution structure of a papaya barwin-like protein (crystal form 2)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.05 Å
  • R-Value Free: 0.170
  • R-Value Work: 0.143

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

High-resolution structure of a papaya plant-defence barwin-like protein solved by in-house sulfur-SAD phasing.

Huet, J.Teinkela Mbosso, E.J.Soror, S.Meyer, F.Looze, Y.Wintjens, R.Wohlkonig, A.

(2013) Acta Crystallogr.,Sect.D 69: 2017-2026

  • DOI: 10.1107/S0907444913018015
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • The first crystal structure of a barwin-like protein, named carwin, has been determined at high resolution by single-wavelength anomalous diffraction (SAD) phasing using the six intrinsic S atoms present in the protein. The barwin-like protein was pu ...

    The first crystal structure of a barwin-like protein, named carwin, has been determined at high resolution by single-wavelength anomalous diffraction (SAD) phasing using the six intrinsic S atoms present in the protein. The barwin-like protein was purified from Carica papaya latex and crystallized in the orthorhombic space group P212121. Using in-house Cu Kα X-ray radiation, 16 cumulative diffraction data sets were acquired to increase the signal-to-noise level and thereby the anomalous scattering signal. A sequence-database search on the papaya genome identified two carwin isoforms of 122 residues in length, both containing six S atoms that yield an estimated Bijvoet ratio of 0.93% at 1.54 Å wavelength. A systematic analysis of data quality and redundancy was performed to assess the capacity to locate the S atoms and to phase the data. It was observed that the crystal decay was low during data collection and that successful S-SAD phasing could be obtained with a relatively low data multiplicity of about 7. Using a synchrotron source, high-resolution data (1 Å) were collected from two different crystal forms of the papaya latex carwin. The refined structures showed a central β-barrel of six strands surrounded by several α-helices and loops. The β-barrel of carwin appears to be a common structural module that is shared within several other unrelated proteins. Finally, the possible biological function of the protein is discussed.


    Organizational Affiliation

    Laboratoire des Biopolymères et des Nanomatériaux Supramoléculaires (CP206/04), Faculté de Pharmacie, Université Libre de Bruxelles, B-1050 Brussels, Belgium.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
papaya barwin-like protein
A, B
122Carica papayaMutation(s): 0
Find proteins for U5HK42 (Carica papaya)
Go to UniProtKB:  U5HK42
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
GOL
Query on GOL

Download SDF File
Download CCD File
B
GLYCEROL
GLYCERIN; PROPANE-1,2,3-TRIOL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
PCA
Query on PCA
A, B
L-PEPTIDE LINKINGC5 H7 N O3GLU
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.05 Å
  • R-Value Free: 0.170
  • R-Value Work: 0.143
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 54.908α = 90.00
b = 56.964β = 90.00
c = 74.202γ = 90.00
Software Package:
Software NamePurpose
XDSdata reduction
SHELXSphasing
REFMACrefinement
XDSdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2013-10-02
    Type: Initial release
  • Version 1.1: 2014-01-15
    Type: Database references
