4JE1 | pdb_00004je1

Crystal structure of thiol peroxidase from BURKHOLDERIA CENOCEPACIA J2315

• PDB DOI: https://doi.org/10.2210/pdb4JE1/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Burkholderia cenocepacia J2315
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2013-02-26 Released: 2013-03-20
• Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.40 Å
• R-Value Free:
  0.171 (Depositor), 0.172 (DCC)
• R-Value Work:
  0.151 (Depositor), 0.151 (DCC)
• R-Value Observed:
  0.152 (Depositor)

Literature

Crystal structure of thiol peroxidase from BURKHOLDERIA CENOCEPACIA J2315

SSGCID, Davies, D.R., Abendroth, J.A., Clifton, M.C., Edwards, T., Lorimer, D.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 36.61 kDa
• Atom Count: 2,990
• Modeled Residue Count: 340
• Deposited Residue Count: 350
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Probable thiol peroxidase	A, B	175	Burkholderia cenocepacia J2315	Mutation(s): 0  Gene Names: tpx, BceJ2315_33620, BCAL3424 EC: 1.11.1 (PDB Primary Data), 1.11.1.24 (UniProt)
UniProt
Find proteins for B4E5V4 (Burkholderia cenocepacia (strain ATCC BAA-245 / DSM 16553 / LMG 16656 / NCTC 13227 / J2315 / CF5610)) Explore B4E5V4  Go to UniProtKB:  B4E5V4

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
EDO	C [auth B]	1,2-ETHANEDIOL C2 H6 O2 LYCAIKOWRPUZTN-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.40 Å
• R-Value Free:  0.171 (Depositor), 0.172 (DCC)
• R-Value Work:  0.151 (Depositor), 0.151 (DCC)
• R-Value Observed: 0.152 (Depositor)

Diffraction Data: https://doi.org/10.18430/M34JE1

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 38.91	α = 88.13
b = 44.29	β = 101.34
c = 53.08	γ = 115.1

Software Package:

Software Name	Purpose
PHASER	phasing
REFMAC	refinement

Structure Validation

Entry History

Deposition Data

• Released Date: 2013-03-20
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Revision History

• Version 1.0: 2013-03-20
  Type: Initial release

• Version 1.1: 2016-05-25
  Changes: Database references
• Version 1.2: 2024-11-20
  Changes: Data collection, Database references, Derived calculations, Structure summary
