4J5V | pdb_00004j5v

Crystal structure of p19 in complex with double-helical RNA 19mer p(CAG)3C(CCG)3

• PDB DOI: https://doi.org/10.2210/pdb4J5V/pdb
• NAKB: 4J5V

• Classification: RNA BINDING PROTEIN/RNA
• Organism(s): Tomato bushy stunt virus
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2013-02-10 Released: 2014-02-12
• Deposition Author(s): Tamjar, J., Popov, A.N., Malinina, L.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.15 Å
• R-Value Free:
  0.214 (Depositor), 0.220 (DCC)
• R-Value Work:
  0.172 (Depositor), 0.172 (DCC)
• R-Value Observed:
  0.174 (Depositor)

Literature

Structural insights into CNG-repetitive RNAs associated with human Trinucleotide Repeat Expansion Diseases (TREDs)

Tamjar, J., Katorcha, E., Cabo, A., Delgado, S., Popov, A.N., Malinina, L.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 21.35 kDa
• Atom Count: 1,595
• Modeled Residue Count: 141
• Deposited Residue Count: 146
• Unique protein chains: 1
• Unique nucleic acid chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
RNA silencing suppressor p19	A	127	Tomato bushy stunt virus	Mutation(s): 0  Gene Names: ORF4
UniProt
Find proteins for P69517 (Tomato bushy stunt virus (strain Ja9)) Explore P69517  Go to UniProtKB:  P69517

Entity ID: 2
Molecule	Chains	Length	Organism	Image
5'-R(P*CP*AP*GP*CP*AP*GP*CP*AP*GP*CP*CP*CP*GP*CP*CP*GP*CP*CP*G)-3'	B	19	N/A

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth B], I [auth B], J [auth B]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.15 Å
• R-Value Free:  0.214 (Depositor), 0.220 (DCC)
• R-Value Work:  0.172 (Depositor), 0.172 (DCC)
• R-Value Observed: 0.174 (Depositor)

Space Group: H 3 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 90.219	α = 90
b = 90.219	β = 90
c = 148.039	γ = 120

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
ADSC	data collection
HKL-2000	data reduction
HKL-2000	data scaling
REFMAC	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2014-02-12
Deposition Author(s): Tamjar, J., Popov, A.N., Malinina, L.

Revision History

• Version 1.0: 2014-02-12
  Type: Initial release

• Version 1.1: 2017-11-15
  Changes: Refinement description
• Version 1.2: 2024-02-28
  Changes: Data collection, Database references, Derived calculations
