4IQ4

Structure of a 16 nm protein cage designed by fusing symmetric oligomeric domains, triple mutant, P21212 form


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.495 Å
  • R-Value Free: 0.231
  • R-Value Work: 0.200

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Structure and flexibility of nanoscale protein cages designed by symmetric self-assembly.

Lai, Y.T.Tsai, K.L.Sawaya, M.R.Asturias, F.J.Yeates, T.O.

(2013) J.Am.Chem.Soc. 135: 7738-7743

  • DOI: 10.1021/ja402277f
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Designing protein molecules that self-assemble into complex architectures is an outstanding goal in the area of nanobiotechnology. One design strategy for doing this involves genetically fusing together two natural proteins, each of which is known to ...

    Designing protein molecules that self-assemble into complex architectures is an outstanding goal in the area of nanobiotechnology. One design strategy for doing this involves genetically fusing together two natural proteins, each of which is known to form a simple oligomer on its own (e.g., a dimer or trimer). If two such components can be fused in a geometrically predefined configuration, that designed subunit can, in principle, assemble into highly symmetric architectures. Initial experiments showed that a 12-subunit tetrahedral cage, 16 nm in diameter, could be constructed following such a procedure [Padilla, J. E.; et al. Proc. Natl. Acad. Sci. U.S.A. 2001, 98, 2217; Lai, Y. T.; et al. Science 2012, 336, 1129]. Here we characterize multiple crystal structures of protein cages constructed in this way, including cages assembled from two mutant forms of the same basic protein subunit. The flexibilities of the designed assemblies and their deviations from the target model are described, along with implications for further design developments.


    Organizational Affiliation

    Department of Bioengineering, University of California, Los Angeles, California 90095, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Non-haem bromoperoxidase BPO-A2, Matrix protein 1
A, B, C, D, E, F
456Kitasatospora aureofaciensInfluenza A virus (strain A/Puerto Rico/8/1934 H1N1)
This entity is chimeric
Mutation(s): 2
Gene Names: bpoA2, M
EC: 1.11.1.-
Find proteins for P29715 (Kitasatospora aureofaciens)
Go to UniProtKB:  P29715
Find proteins for P03485 (Influenza A virus (strain A/Puerto Rico/8/1934 H1N1))
Go to UniProtKB:  P03485
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.495 Å
  • R-Value Free: 0.231
  • R-Value Work: 0.200
  • Space Group: P 21 21 2
Unit Cell:
Length (Å)Angle (°)
a = 126.710α = 90.00
b = 137.870β = 90.00
c = 171.780γ = 90.00
Software Package:
Software NamePurpose
XSCALEdata scaling
PHASERphasing
PDB_EXTRACTdata extraction
XDSdata reduction
PHENIXrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2013-07-24
    Type: Initial release
  • Version 1.1: 2017-08-16
    Type: Refinement description, Source and taxonomy
