4INJ | pdb_00004inj

Crystal structure of the S111A mutant of member of MccF clade from Listeria monocytogenes EGD-e with product

• PDB DOI: https://doi.org/10.2210/pdb4INJ/pdb

• Classification: HYDROLASE
• Organism(s): Listeria monocytogenes EGD-e
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): Yes


• Deposited: 2013-01-04 Released: 2013-02-20
• Deposition Author(s): Nocek, B., Tikhonov, A., Severinov, K., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free:
  0.243 (Depositor), 0.223 (DCC)
• R-Value Work:
  0.190 (Depositor)
• R-Value Observed:
  0.193 (Depositor)

Starting Model: experimental

Literature

Crystal structure of the S111A mutant of member of MccF clade from Listeria monocytogenes EGD-e with product

Nocek, B., Tikhonov, A., Severinov, K., Anderson, W.F., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 73.48 kDa
• Atom Count: 5,259
• Modeled Residue Count: 652
• Deposited Residue Count: 654
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lmo1638 protein	A, B	327	Listeria monocytogenes EGD-e	Mutation(s): 1  Gene Names: lmo1638
UniProt
Find proteins for Q8Y6P6 (Listeria monocytogenes serovar 1/2a (strain ATCC BAA-679 / EGD-e)) Explore Q8Y6P6  Go to UniProtKB:  Q8Y6P6

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
LMS	C [auth A], F [auth B]	[(2R,3S,4R,5R)-5-(6-AMINO-9H-PURIN-9-YL)-3,4-DIHYDROXYTETRAHYDRO-2-FURANYL]METHYL SULFAMATE C10 H14 N6 O6 S GNZLUJQJDPRUTD-KQYNXXCUSA-N
PEG	G [auth B]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N
GOL	E [auth A], H [auth B], I [auth B], J [auth B], K [auth B]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
MG	D [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free:  0.243 (Depositor), 0.223 (DCC)
• R-Value Work:  0.190 (Depositor)
• R-Value Observed: 0.193 (Depositor)

Diffraction Data: https://doi.org/10.18430/m34inj

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 92.242	α = 90
b = 92.242	β = 90
c = 205.776	γ = 90

Software Package:

Software Name	Purpose
SBC-Collect	data collection
MOLREP	phasing
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2013-02-20
Deposition Author(s): Nocek, B., Tikhonov, A., Severinov, K., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

Revision History

• Version 1.0: 2013-02-20
  Type: Initial release

• Version 1.1: 2017-11-15
  Changes: Database references
• Version 1.2: 2023-09-20
  Changes: Data collection, Database references, Derived calculations, Refinement description
