4I9Z | pdb_00004i9z

Crystal structure of the PDE5A1 catalytic domain in complex with novel inhibitors


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.08 Å
  • R-Value Free:
    0.237 (Depositor), 0.241 (DCC)
  • R-Value Work:
    0.201 (Depositor), 0.202 (DCC)
  • R-Value Observed:
    0.202 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 4I9Z

Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history

Literature

Exploration of the 5-bromopyrimidin-4(3H)-ones as potent inhibitors of PDE5.

Gong, X.Wang, G.Ren, J.Liu, Z.Wang, Z.Chen, T.Yang, X.Jiang, X.Shen, J.Jiang, H.Aisa, H.A.Xu, Y.Li, J.

(2013) Bioorg Med Chem Lett 23: 4944-4947

  • DOI: https://doi.org/10.1016/j.bmcl.2013.06.062
  • Primary Citation Related Structures:
    4I9Z, 4IA0

  • PubMed Abstract:

    The substituents both at the 6-position of the 5-bromopyrimidinone ring and at the 5'-position of the phenyl ring of 5-bromopyrimidin-4(3H)-ones were explored. 5-Bromo-6-isopropyl-2-(2-propoxy-phenyl)pyrimidin-4(3H)-one was identified as a new scaffold for potent PDE5 inhibitors. The crystal structures of PDE5/2e and PDE5/10a complexes provided a structural basis for the inhibition of 5-bromopyrimidinones to PDE5. In addition, it was also found that there is a great tolerance for the substitution at the 5'-position of the phenyl ring of 5-bormopyrimidinones and the resulted compound 13a has the highest inhibition activity to PDE5 (IC50, 1.7 nM).


  • Organizational Affiliation
    • Key Laboratory of Xinjiang Indigenous Medicinal Plants Resource Utilization, Xinjiang Technical Institute of Physics and Chemistry, Chinese Academy of Sciences, Urumiqi 830011, China.

Macromolecule Content

  • Total Structure Weight: 40.88 kDa
  • Atom Count: 2,572
  • Modeled Residue Count: 296
  • Deposited Residue Count: 347
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
cGMP-specific 3',5'-cyclic phosphodiesterase347Homo sapiensMutation(s): 0
Gene Names: PDE5PDE5A
EC: 3.1.4.35
UniProt & NIH Common Fund Data Resources
Find proteins for O76074 (Homo sapiens)
Explore O76074
Go to UniProtKB:  O76074
PHAROS:  O76074
GTEx:  ENSG00000138735
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO76074
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
5BA

Query on 5BA



Download:Ideal Coordinates CCD File
B [auth A]5-bromo-2-{5-[(4-methylpiperazin-1-yl)acetyl]-2-propoxyphenyl}-6-(propan-2-yl)pyrimidin-4(3H)-one
C23 H31 Br N4 O3
WTKMCYZVMOTXKM-UHFFFAOYSA-N
PEG

Query on PEG



Download:Ideal Coordinates CCD File
E [auth A],
F [auth A]
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
ZN

Query on ZN



Download:Ideal Coordinates CCD File
C [auth A]ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG

Query on MG



Download:Ideal Coordinates CCD File
D [auth A]MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Binding Affinity Annotations
IDSourceBinding Affinity
5BA BindingDB:  4I9Z IC50: 18 (nM) from 1 assay(s)

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.08 Å
  • R-Value Free:  0.237 (Depositor), 0.241 (DCC)
  • R-Value Work:  0.201 (Depositor), 0.202 (DCC)
  • R-Value Observed: 0.202 (Depositor)
Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 74.85α = 90
b = 74.85β = 90
c = 132.28γ = 120
Software Package:
Software NamePurpose
XSCALEdata scaling
PHASERphasing
PHENIXrefinement
PDB_EXTRACTdata extraction
Blu-Icedata collection
XDSdata reduction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-01-01
    Type: Initial release
  • Version 1.1: 2023-11-08
    Changes: Data collection, Database references, Derived calculations, Refinement description
