4HZL

Neutralizing antibody mAb#8 in complex with the Epitope II of HCV E2 envelope protein


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.85 Å
  • R-Value Free: 0.277
  • R-Value Work: 0.221
  • R-Value Observed: 0.224

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structural evidence for a bifurcated mode of action in the antibody-mediated neutralization of hepatitis C virus.

Deng, L.Zhong, L.Struble, E.Duan, H.Ma, L.Harman, C.Yan, H.Virata-Theimer, M.L.Zhao, Z.Feinstone, S.Alter, H.Zhang, P.

(2013) Proc Natl Acad Sci U S A 110: 7418-7422

  • DOI: 10.1073/pnas.1305306110
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • Hepatitis C virus (HCV) envelope glycoprotein E2 has been considered as a major target for vaccine design. Epitope II, mapped between residues 427-446 within the E2 protein, elicits antibodies that are either neutralizing or nonneutralizing. The fund ...

    Hepatitis C virus (HCV) envelope glycoprotein E2 has been considered as a major target for vaccine design. Epitope II, mapped between residues 427-446 within the E2 protein, elicits antibodies that are either neutralizing or nonneutralizing. The fundamental mechanism of antibody-mediated neutralization at epitope II remains to be defined at the atomic level. Here we report the crystal structure of the epitope II peptide in complex with a monoclonal antibody (mAb#8) capable of neutralizing HCV. The complex structure revealed that this neutralizing antibody engages epitope II via interactions with both the C-terminal α-helix and the N-terminal loop using a bifurcated mode of action. Our structural insights into the key determinants for the antibody-mediated neutralization may contribute to the immune prophylaxis of HCV infection and the development of an effective HCV vaccine.


    Organizational Affiliation

    Division of Hematology, Office of Blood Research and Review, Center for Biologics Evaluation and Research, Food and Drug Administration, Bethesda, MD 20892, USA.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Fab heavy chainA, H222Mus musculusMutation(s): 0
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Fab light chainB, L217Mus musculusMutation(s): 0
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
  • Find similar proteins by: Sequence   |   Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
E2 envelop proteinE, F17Recombinant Hepatitis C virus H77(5'UTR-NS2)/JFH1_V787A,Q1247LMutation(s): 0
Find proteins for F5BWY6 (Recombinant Hepatitis C virus H77(5'UTR-NS2)/JFH1_V787A,Q1247L)
Explore F5BWY6
Go to UniProtKB:  F5BWY6
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.85 Å
  • R-Value Free: 0.277
  • R-Value Work: 0.221
  • R-Value Observed: 0.224
  • Space Group: P 43 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 137.252α = 90
b = 137.252β = 90
c = 140.49γ = 90
Software Package:
Software NamePurpose
ADSCdata collection
PHASERphasing
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

  • Deposited Date: 2012-11-15
  • Released Date: 2013-05-01
  • Deposition Author(s): Deng, L., Zhang, P.

Revision History

  • Version 1.0: 2013-05-01
    Type: Initial release
  • Version 1.1: 2013-05-15
    Changes: Database references
