4HYF

Structural basis and SAR for OD 270, a lead stage 1,2,4-triazole based specific Tankyrase1/2 inhibitor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.225
  • R-Value Work: 0.211
  • R-Value Observed: 0.212

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structural Basis and SAR for G007-LK, a Lead Stage 1,2,4-Triazole Based Specific Tankyrase 1/2 Inhibitor.

Voronkov, A.Holsworth, D.D.Waaler, J.Wilson, S.R.Ekblad, B.Perdreau-Dahl, H.Dinh, H.Drewes, G.Hopf, C.Morth, J.P.Krauss, S.

(2013) J Med Chem 56: 3012-3023

  • DOI: 10.1021/jm4000566
  • Primary Citation of Related Structures:
    4HYF

  • PubMed Abstract:
  • Tankyrases 1 and 2 (TNKS1/2) are promising pharmacological biotargets with possible applications for the development of novel anticancer therapeutics. A focused structure-activity relationship study was conducted based on the tankyrase inhibitor JW74 (1) ...

    Tankyrases 1 and 2 (TNKS1/2) are promising pharmacological biotargets with possible applications for the development of novel anticancer therapeutics. A focused structure-activity relationship study was conducted based on the tankyrase inhibitor JW74 (1). Chemical analoging of 1 improved the 1,2,4-triazole based core and led to 4-{5-[(E)-2-{4-(2-chlorophenyl)-5-[5-(methylsulfonyl)pyridin-2-yl]-4H-1,2,4-triazol-3-yl}ethenyl]-1,3,4-oxadiazol-2-yl}benzonitrile (G007-LK), a potent, "rule of 5" compliant and a metabolically stable TNKS1/2 inhibitor. G007-LK (66) displayed high selectivity toward tankyrases 1 and 2 with biochemical IC50 values of 46 nM and 25 nM, respectively, and a cellular IC50 value of 50 nM combined with an excellent pharmacokinetic profile in mice. The PARP domain of TNKS2 was cocrystallized with 66, and the X-ray structure was determined at 2.8 Å resolution in the space group P3221. The structure revealed that 66 binds to unique structural features in the extended adenosine binding pocket which forms the structural basis for the compound's high target selectivity and specificity. Our study provides a significantly optimized compound for targeting TNKS1/2 in vitro and in vivo.


    Organizational Affiliation

    SFI CAST Biomedical Innovation Center, Unit for Cell Signaling, Oslo University Hospital, Forskningsparken, Gaustadalleén 21, 0349 Oslo, Norway.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Tankyrase-2 ABC240Homo sapiensMutation(s): 0
Gene Names: PARP5BTANK2TNKLTNKS2
EC: 2.4.2.30 (PDB Primary Data), 2.4.2 (UniProt)
Find proteins for Q9H2K2 (Homo sapiens)
Explore Q9H2K2
Go to UniProtKB:  Q9H2K2
NIH Common Fund Data Resources
PHAROS:  Q9H2K2
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
1AK
Query on 1AK

Download Ideal Coordinates CCD File
A, B, C
4-{5-[(E)-2-{4-(2-chlorophenyl)-5-[5-(methylsulfonyl)pyridin-2-yl]-4H-1,2,4-triazol-3-yl}ethenyl]-1,3,4-oxadiazol-2-yl}benzonitrile
C25 H16 Cl N7 O3 S
HIWVLHPKZNBSBE-OUKQBFOZSA-N
 Ligand Interaction
NCA
Query on NCA

Download Ideal Coordinates CCD File
A, B, C
NICOTINAMIDE
C6 H6 N2 O
DFPAKSUCGFBDDF-UHFFFAOYSA-N
 Ligand Interaction
ZN
Query on ZN

Download Ideal Coordinates CCD File
A, B, C
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
1AKIC50 :  25   nM  PDBBind
1AKIC50:  25   nM  BindingDB
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.225
  • R-Value Work: 0.211
  • R-Value Observed: 0.212
  • Space Group: P 32 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 151.54α = 90
b = 151.54β = 90
c = 140.52γ = 120
Software Package:
Software NamePurpose
RemDAqdata collection
PHASERphasing
PHENIXrefinement
PROCESSdata reduction
SCALAdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2013-03-20
    Type: Initial release
  • Version 1.1: 2013-05-01
    Changes: Database references
  • Version 1.2: 2017-11-15
    Changes: Refinement description
