4HLJ | pdb_00004hlj

Axon Guidance Receptor

PDB DOI: https://doi.org/10.2210/pdb4HLJ/pdb

Classification: CELL ADHESION
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2012-10-17 Released: 2013-11-20
Deposition Author(s): Barak, R., Opatowsky, Y.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.211 (Depositor), 0.210 (DCC)
R-Value Work:
0.184 (Depositor), 0.183 (DCC)
R-Value Observed:
0.187 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4HLJ

This is version 1.1 of the entry. See complete history.

Literature

Crystal Structure of Axon Guidance Receptor

Barak, R., Opatowsky, Y.

To be published.

Macromolecule Content

Total Structure Weight: 26.6 kDa
Atom Count: 2,010
Modeled Residue Count: 223
Deposited Residue Count: 240
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Roundabout homolog 1	A	240	Homo sapiens	Mutation(s): 1 Gene Names: DUTT1, ROBO1
UniProt & NIH Common Fund Data Resources
Find proteins for Q9Y6N7 (Homo sapiens) Explore Q9Y6N7 Go to UniProtKB: Q9Y6N7
PHAROS: Q9Y6N7 GTEx: ENSG00000169855
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9Y6N7
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
1PE Query on 1PE Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	PENTAETHYLENE GLYCOL C₁₀ H₂₂ O₆ JLFNLZLINWHATN-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.211 (Depositor), 0.210 (DCC)
R-Value Work: 0.184 (Depositor), 0.183 (DCC)
R-Value Observed: 0.187 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 28.7	α = 90
b = 77.71	β = 90
c = 91.9	γ = 90

Software Package:

Software Name	Purpose
MxCuBE	data collection
SOLVE	phasing
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2013-11-20

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2013-11-20
Type: Initial release
Version 1.1: 2024-03-20
Changes: Data collection, Database references, Derived calculations
