Crystal structure of the 5-coordinate ferric heme-binding PAS domain of Aer2 from P. aeruginosa

Experimental Data Snapshot

  • Resolution: 2.30 Å
  • R-Value Free: 0.248
  • R-Value Work: 0.228
  • R-Value Observed: 0.230

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.3 of the entry. See complete history


Architecture of the soluble receptor Aer2 indicates an in-line mechanism for PAS and HAMP domain signaling.

Airola, M.V.Huh, D.Sukomon, N.Widom, J.Sircar, R.Borbat, P.P.Freed, J.H.Watts, K.J.Crane, B.R.

(2013) J Mol Biol 425: 886-901

  • DOI: https://doi.org/10.1016/j.jmb.2012.12.011
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Bacterial receptors typically contain modular architectures with distinct functional domains that combine to send signals in response to stimuli. Although the properties of individual components have been investigated in many contexts, there is little information about how diverse sets of modules work together in full-length receptors. Here, we investigate the architecture of Aer2, a soluble gas-sensing receptor that has emerged as a model for PAS (Per-Arnt-Sim) and poly-HAMP (histidine kinase-adenylyl cyclase-methyl-accepting chemotaxis protein-phosphatase) domain signaling. The crystal structure of the heme-binding PAS domain in the ferric, ligand-free form, in comparison to the previously determined cyanide-bound state, identifies conformational changes induced by ligand binding that are likely essential for the signaling mechanism. Heme-pocket alternations share some similarities with the heme-based PAS sensors FixL and EcDOS but propagate to the Iβ strand in a manner predicted to alter PAS-PAS associations and the downstream HAMP junction within full-length Aer2. Small-angle X-ray scattering of PAS and poly-HAMP domain fragments of increasing complexity allow unambiguous domain assignments and reveal a linear quaternary structure. The Aer2 PAS dimeric crystal structure fits well within ab initio small-angle X-ray scattering molecular envelopes, and pulsed dipolar ESR measurements of inter-PAS distances confirm the crystallographic PAS arrangement within Aer2. Spectroscopic and pull-down assays fail to detect direct interactions between the PAS and HAMP domains. Overall, the Aer2 signaling mechanism differs from the Escherichia coli Aer paradigm, where side-on PAS-HAMP contacts are key. We propose an in-line model for Aer2 signaling, where ligand binding induces alterations in PAS domain structure and subunit association that is relayed through the poly-HAMP junction to downstream domains.

  • Organizational Affiliation

    Department of Chemistry and Chemical Biology, Cornell University, Ithaca, NY 14853, USA.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Aerotaxis transducer Aer2A,
C [auth D],
D [auth G]
121Pseudomonas aeruginosaMutation(s): 2
Gene Names: aer2
Find proteins for Q9I6V6 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore Q9I6V6
Go to UniProtKB:  Q9I6V6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9I6V6
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on HEM

Download Ideal Coordinates CCD File
E [auth A],
G [auth B],
I [auth D],
K [auth G]
C34 H32 Fe N4 O4
Query on GOL

Download Ideal Coordinates CCD File
H [auth B],
J [auth D],
L [auth G],
M [auth G]
C3 H8 O3
Query on CL

Download Ideal Coordinates CCD File
Experimental Data & Validation

Experimental Data

  • Resolution: 2.30 Å
  • R-Value Free: 0.248
  • R-Value Work: 0.228
  • R-Value Observed: 0.230
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 67.365α = 90
b = 67.435β = 90
c = 117.868γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
PDB_EXTRACTdata extraction
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2013-01-09
    Type: Initial release
  • Version 1.1: 2013-05-22
    Changes: Database references
  • Version 1.2: 2017-11-15
    Changes: Refinement description
  • Version 1.3: 2024-02-28
    Changes: Data collection, Database references, Derived calculations
