4HFW

Anti Rotavirus Antibody


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.601 Å
  • R-Value Free: 0.233
  • R-Value Work: 0.186

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Human Rotavirus VP6-Specific Antibodies Mediate Intracellular Neutralization by Binding to a Quaternary Structure in the Transcriptional Pore.

Aiyegbo, M.S.Sapparapu, G.Spiller, B.W.Eli, I.M.Williams, D.R.Kim, R.Lee, D.E.Liu, T.Li, S.Woods, V.L.Nannemann, D.P.Meiler, J.Stewart, P.L.Crowe, J.E.

(2013) Plos One 8: e61101-e61101

  • DOI: 10.1371/journal.pone.0061101

  • PubMed Abstract:
  • Several live attenuated rotavirus (RV) vaccines have been licensed, but the mechanisms of protective immunity are still poorly understood. The most frequent human B cell response is directed to the internal protein VP6 on the surface of double-layere ...

    Several live attenuated rotavirus (RV) vaccines have been licensed, but the mechanisms of protective immunity are still poorly understood. The most frequent human B cell response is directed to the internal protein VP6 on the surface of double-layered particles, which is normally exposed only in the intracellular environment. Here, we show that the canonical VP6 antibodies secreted by humans bind to such particles and inhibit viral transcription. Polymeric IgA RV antibodies mediated an inhibitory effect against virus replication inside cells during IgA transcytosis. We defined the recognition site on VP6 as a quaternary epitope containing a high density of charged residues. RV human mAbs appear to bind to a negatively-charged patch on the surface of the Type I channel in the transcriptionally active particle, and they sterically block the channel. This unique mucosal mechanism of viral neutralization, which is not apparent from conventional immunoassays, may contribute significantly to human immunity to RV.


    Organizational Affiliation

    Department of Pathology, Microbiology and Immunology, Vanderbilt Medical Center, Nashville, Tennessee, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
6-26 Fab Light chain
L, A
213N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
6-26 Fab Heavy chain
H, B
223N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A, H
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.601 Å
  • R-Value Free: 0.233
  • R-Value Work: 0.186
  • Space Group: P 1 21 1
Unit Cell:
Length (Å)Angle (°)
a = 68.100α = 90.00
b = 97.920β = 108.88
c = 94.230γ = 90.00
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
MOLREPphasing
SCALAdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2013-05-29
    Type: Initial release
