4HET | pdb_00004het

Crystal structure of a putative glycoside hydrolase (BT3745) from Bacteroides thetaiotaomicron VPI-5482 at 2.10 A resolution

PDB DOI: https://doi.org/10.2210/pdb4HET/pdb

Classification: HYDROLASE
Organism(s): Bacteroides thetaiotaomicron VPI-5482
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2012-10-04 Released: 2012-10-24
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free:
0.207 (Depositor), 0.220 (DCC)
R-Value Work:
0.178 (Depositor), 0.190 (DCC)
R-Value Observed:
0.180 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.4 of the entry. See complete history.

Literature

Crystal structure of a hypothetical glycoside hydrolase (BT3745) from Bacteroides thetaiotaomicron VPI-5482 at 2.10 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 79.99 kDa
Atom Count: 5,759
Modeled Residue Count: 688
Deposited Residue Count: 720
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
HYPOTHETICAL GLYCOSIDE HYDROLASE	A, B	360	Bacteroides thetaiotaomicron VPI-5482	Mutation(s): 0 Gene Names: BT_3745, NP_812656.1
UniProt
Find proteins for Q8A1C1 (Bacteroides thetaiotaomicron (strain ATCC 29148 / DSM 2079 / JCM 5827 / CCUG 10774 / NCTC 10582 / VPI-5482 / E50)) Explore Q8A1C1 Go to UniProtKB: Q8A1C1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q8A1C1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth B]	C [auth A], D [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free: 0.207 (Depositor), 0.220 (DCC)
R-Value Work: 0.178 (Depositor), 0.190 (DCC)
R-Value Observed: 0.180 (Depositor)

Diffraction Data: https://doi.org/10.18430/M34HET

Space Group: P 6₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 180.385	α = 90
b = 180.385	β = 90
c = 63.752	γ = 120

Software Package:

Software Name	Purpose
MolProbity	model building
PDB_EXTRACT	data extraction
SOLVE	phasing
SCALA	data scaling
REFMAC	refinement
MOSFLM	data reduction

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2012-10-24

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2012-10-24
Type: Initial release
Version 1.1: 2014-12-24
Changes: Structure summary
Version 1.2: 2017-11-15
Changes: Refinement description
Version 1.3: 2023-02-01
Changes: Database references, Derived calculations
Version 1.4: 2024-10-30
Changes: Data collection, Structure summary
