4HBS | pdb_00004hbs

Crystal structure of a putative hydrolase (BACOVA_04882) from Bacteroides ovatus ATCC 8483 at 2.80 A resolution

PDB DOI: https://doi.org/10.2210/pdb4HBS/pdb

Classification: HYDROLASE
Organism(s): Bacteroides ovatus ATCC 8483
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2012-09-28 Released: 2012-10-24
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.80 Å
R-Value Free:
0.209 (Depositor), 0.193 (DCC)
R-Value Work:
0.186 (Depositor)
R-Value Observed:
0.187 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4HBS

This is version 1.3 of the entry. See complete history.

Literature

Crystal structure of a putative hydrolase (BACOVA_04882) from Bacteroides ovatus ATCC 8483 at 2.80 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 49.32 kDa
Atom Count: 3,395
Modeled Residue Count: 406
Deposited Residue Count: 416
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative hydrolase	A	416	Bacteroides ovatus ATCC 8483	Mutation(s): 0 Gene Names: ZP_02067871.1

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain D [auth A] SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A], D [auth A], E [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.80 Å
R-Value Free: 0.209 (Depositor), 0.193 (DCC)
R-Value Work: 0.186 (Depositor)
R-Value Observed: 0.187 (Depositor)

Diffraction Data:

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 104.4	α = 90
b = 104.4	β = 90
c = 116.131	γ = 120

Software Package:

Software Name	Purpose
MolProbity	model building
PDB_EXTRACT	data extraction
SHELX	phasing
SHARP	phasing
XSCALE	data scaling
BUSTER-TNT	refinement
XDS	data reduction
SHELXD	phasing
BUSTER	refinement

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2012-10-24

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2012-10-24
Type: Initial release
Version 1.1: 2017-11-15
Changes: Refinement description
Version 1.2: 2023-02-01
Changes: Database references, Derived calculations
Version 1.3: 2024-11-06
Changes: Data collection, Structure summary
