4H11

Interaction partners of PSD-93 studied by X-ray crystallography and fluorescent polarization spectroscopy


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.67 Å
  • R-Value Free: 0.213
  • R-Value Work: 0.172

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Interaction partners of PSD-93 studied by X-ray crystallography and fluorescence polarization spectroscopy.

Fiorentini, M.Bach, A.Stromgaard, K.Kastrup, J.S.Gajhede, M.

(2013) Acta Crystallogr.,Sect.D 69: 587-594

  • DOI: 10.1107/S0907444912051839

  • PubMed Abstract:
  • PSD-93 (chapsyn-110, DLG2) is a member of the family of membrane-associated guanylate kinase (MAGUK) proteins. The MAGUK proteins are involved in receptor localization and signalling pathways. The best characterized MAGUK protein, PSD-95, is known to ...

    PSD-93 (chapsyn-110, DLG2) is a member of the family of membrane-associated guanylate kinase (MAGUK) proteins. The MAGUK proteins are involved in receptor localization and signalling pathways. The best characterized MAGUK protein, PSD-95, is known to be involved in NMDA receptor signalling via its PDZ domains. The PDZ domains of PSD-95 and PSD-93 are structurally very similar, but relatively little is known about the function of PSD-93. PSD-93 has been suggested to interact with GluD2 from the family of ionotropic glutamate receptors. Here, the interactions of four residues (GTSI) representing the extreme C-terminus of GluD2 with PSD-93 PDZ1 have been investigated in the crystalline phase. Two different binding modes of these residues were observed, suggesting that the peptide is not tightly bound to PSD-93 PDZ1. In accordance, the two N-terminal PSD-93 PDZ domains show no appreciable binding affinity for a GluD2-derived C-terminal octapeptide, whereas micromolar affinity was observed for a GluN2B-derived C-terminal octapeptide. This indicates that if present, the interactions between GluD2 and PSD-93 involve more than the extreme terminus of the receptor. In contrast, the tumour-suppressor protein SCRIB PDZ3 shows low micromolar affinity towards the GluD2-derived octapeptide, which is in agreement with previous findings using high-throughput assays.


    Organizational Affiliation

    Department of Drug Design and Pharmacology, Faculty of Health and Medical Sciences, University of Copenhagen, Copenhagen, Denmark.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Disks large homolog 2
A, B
103Rattus norvegicusMutation(s): 0
Gene Names: Dlg2 (Dlgh2)
Find proteins for Q63622 (Rattus norvegicus)
Go to UniProtKB:  Q63622
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
B
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
ACT
Query on ACT

Download SDF File
Download CCD File
B
ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.67 Å
  • R-Value Free: 0.213
  • R-Value Work: 0.172
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 33.200α = 90.00
b = 45.550β = 90.00
c = 104.240γ = 90.00
Software Package:
Software NamePurpose
SCALAdata scaling
PHENIXrefinement
MOSFLMdata reduction
ADSCdata collection
PHASERphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2013-04-03
    Type: Initial release
  • Version 1.1: 2018-03-07
    Type: Data collection
