4GCA | pdb_00004gca

Complex of Aldose Reductase with inhibitor IDD 1219

PDB DOI: https://doi.org/10.2210/pdb4GCA/pdb

Classification: OXIDOREDUCTASE/OXIDOREDUCTASE INHIBITOR
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2012-07-30 Released: 2013-07-31
Deposition Author(s): Podjarny, A.D., Van Zandt, M., Geraci, L.S.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 0.90 Å
R-Value Free:
0.145 (Depositor), 0.151 (DCC)
R-Value Work:
0.134 (Depositor)
R-Value Observed:
0.134 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4GCA

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Complex of Aldose Reductase with inhibitor IDD 1219

Podjarny, A.D., Van Zandt, M., Geraci, L.S.

To be published.

Macromolecule Content

Total Structure Weight: 36.88 kDa
Atom Count: 3,507
Modeled Residue Count: 315
Deposited Residue Count: 315
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Aldose reductase	A	315	Homo sapiens	Mutation(s): 0 Gene Names: AKR1B1, ALDR1 EC: 1.1.1.21 (PDB Primary Data), 1.1.1.372 (UniProt), 1.1.1.300 (UniProt), 1.1.1.54 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P15121 (Homo sapiens) Explore P15121 Go to UniProtKB: P15121
PHAROS: P15121 GTEx: ENSG00000085662
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P15121
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAP Query on NAP Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	NADP NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE C₂₁ H₂₈ N₇ O₁₇ P₃ XJLXINKUBYWONI-NNYOXOHSSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
2X9 Query on 2X9 Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	{2,6-dimethyl-5-[(4,5,7-trifluoro-1,3-benzothiazol-2-yl)methyl]pyridin-3-yl}acetic acid C₁₇ H₁₃ F₃ N₂ O₂ S SGWFOCMKXJYHKO-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 0.90 Å
R-Value Free: 0.145 (Depositor), 0.151 (DCC)
R-Value Work: 0.134 (Depositor)
R-Value Observed: 0.134 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 47.102	α = 67.83
b = 47.218	β = 76.96
c = 39.953	γ = 76.15

Software Package:

Software Name	Purpose
SCALEPACK	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
HKL-2000	data collection
HKL-2000	data reduction
AMoRE	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2013-07-31

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2013-07-31
Type: Initial release
Version 1.1: 2024-02-28
Changes: Data collection, Database references, Derived calculations
