4G71 | pdb_00004g71

Structure of Recombinant Cytochrome ba3 Oxidase mutant V236N from Thermus thermophilus

PDB DOI: https://doi.org/10.2210/pdb4G71/pdb

Classification: OXIDOREDUCTASE
Organism(s): Thermus thermophilus HB8
Expression System: Thermus thermophilus
Mutation(s): Yes
Membrane Protein: Yes PDBTM MemProtMD

Deposited: 2012-07-19 Released: 2013-07-24
Deposition Author(s): Li, Y., Chen, Y., Stout, C.D.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.90 Å
R-Value Free:
0.224 (Depositor), 0.227 (DCC)
R-Value Work:
0.180 (Depositor), 0.183 (DCC)
R-Value Observed:
0.182 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Structure of Recombinant Cytochrome ba3 Oxidase mutant V236N from Thermus thermophilus

Li, Y., Chen, Y., Stout, C.D.

To be published.

Macromolecule Content

Total Structure Weight: 93.69 kDa
Atom Count: 6,389
Modeled Residue Count: 751
Deposited Residue Count: 771
Unique protein chains: 3

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cytochrome c oxidase subunit 1	A	569	Thermus thermophilus HB8	Mutation(s): 2 Gene Names: cbaA, TTHA1135 EC: 1.9.3.1 (PDB Primary Data), 7.1.1.9 (UniProt) Membrane Entity: Yes
UniProt
Find proteins for Q5SJ79 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8)) Explore Q5SJ79 Go to UniProtKB: Q5SJ79
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q5SJ79
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Cytochrome c oxidase subunit 2	B	168	Thermus thermophilus HB8	Mutation(s): 0 Gene Names: cbaB, ctaC, TTHA1134 EC: 1.9.3.1 (PDB Primary Data), 7.1.1.9 (UniProt) Membrane Entity: Yes
UniProt
Find proteins for Q5SJ80 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8)) Explore Q5SJ80 Go to UniProtKB: Q5SJ80
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q5SJ80
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Cytochrome c oxidase polypeptide 2A	C	34	Thermus thermophilus HB8	Mutation(s): 0 Gene Names: cbaD, TTHA1133 EC: 1.9.3.1 (PDB Primary Data), 7.1.1.9 (UniProt) Membrane Entity: Yes
UniProt
Find proteins for P82543 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8)) Explore P82543 Go to UniProtKB: P82543
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P82543
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 6 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
HAS Query on HAS Download:Ideal Coordinates CCD File SDF format, chain F [auth A] MOL2 format, chain F [auth A] mmCIF format, chain F [auth A]	F [auth A]	HEME-AS C₅₄ H₆₄ Fe N₄ O₆ PDYODZVCODUKFH-ZOMLSHGTSA-L		Interactions Focus chain F [auth A] Interactions & Density Focus chain F [auth A]
HEM Query on HEM Download:Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	PROTOPORPHYRIN IX CONTAINING FE C₃₄ H₃₂ Fe N₄ O₄ KABFMIBPWCXCRK-RGGAHWMASA-L		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
OLC Query on OLC Download:Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain N [auth A] SDF format, chain P [auth A] SDF format, chain U [auth B] SDF format, chain W [auth C] SDF format, chain X [auth C] SDF format, chain V [auth B] SDF format, chain T [auth B] SDF format, chain R [auth A] SDF format, chain Q [auth A] SDF format, chain O [auth A] SDF format, chain J [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain N [auth A] MOL2 format, chain P [auth A] MOL2 format, chain U [auth B] MOL2 format, chain W [auth C] MOL2 format, chain X [auth C] MOL2 format, chain V [auth B] MOL2 format, chain T [auth B] MOL2 format, chain R [auth A] MOL2 format, chain Q [auth A] MOL2 format, chain O [auth A] MOL2 format, chain J [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A] mmCIF format, chain N [auth A] mmCIF format, chain P [auth A] mmCIF format, chain U [auth B] mmCIF format, chain W [auth C] mmCIF format, chain X [auth C] mmCIF format, chain V [auth B] mmCIF format, chain T [auth B] mmCIF format, chain R [auth A] mmCIF format, chain Q [auth A] mmCIF format, chain O [auth A] mmCIF format, chain J [auth A]	H [auth A] I [auth A] J [auth A] K [auth A] L [auth A] H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], N [auth A], O [auth A], P [auth A], Q [auth A], R [auth A], T [auth B], U [auth B], V [auth B], W [auth C], X [auth C]	(2R)-2,3-dihydroxypropyl (9Z)-octadec-9-enoate C₂₁ H₄₀ O₄ RZRNAYUHWVFMIP-GDCKJWNLSA-N		Interactions Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Focus chain W [auth C] Focus chain X [auth C] Interactions & Density Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Focus chain W [auth C] Focus chain X [auth C]
CUB Query on CUB Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	CU(I)-S-MO(IV)(=O)O-NBIC CLUSTER C₅ H₉ Cu Mo N O₂ S KNSQHRMNQABPBN-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]
CUA Query on CUA Download:Ideal Coordinates CCD File SDF format, chain S [auth B] MOL2 format, chain S [auth B] mmCIF format, chain S [auth B]	S [auth B]	DINUCLEAR COPPER ION Cu₂ ALKZAGKDWUSJED-UHFFFAOYSA-N		Interactions Focus chain S [auth B] Interactions & Density Focus chain S [auth B]
PER Query on PER Download:Ideal Coordinates CCD File SDF format, chain G [auth A] MOL2 format, chain G [auth A] mmCIF format, chain G [auth A]	G [auth A]	PEROXIDE ION O₂ ANAIPYUSIMHBEL-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Interactions & Density Focus chain G [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.90 Å
R-Value Free: 0.224 (Depositor), 0.227 (DCC)
R-Value Work: 0.180 (Depositor), 0.183 (DCC)
R-Value Observed: 0.182 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 144.44	α = 90
b = 98.36	β = 127.81
c = 94.84	γ = 90

Software Package:

Software Name	Purpose
PHASER	phasing
REFMAC	refinement
MOSFLM	data reduction
PROTEUM PLUS	data scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2013-07-24

Deposition Author(s):

Li, Y.

Chen, Y.

Stout, C.D.

Revision History (Full details and data files)

Version 1.0: 2013-07-24
Type: Initial release
Version 1.1: 2024-02-28
Changes: Advisory, Data collection, Database references, Derived calculations
