4G0P

Crystal Structure of Arabidopsis thaliana AGO1 MID domain in complex with UMP


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.8 Å
  • R-Value Free: 0.216
  • R-Value Work: 0.175

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Arabidopsis Argonaute MID domains use their nucleotide specificity loop to sort small RNAs.

Frank, F.Hauver, J.Sonenberg, N.Nagar, B.

(2012) Embo J. 31: 3588-3595

  • DOI: 10.1038/emboj.2012.204
  • Primary Citation of Related Structures:  4G0M, 4G0O, 4G0Q, 4G0X, 4G0Y, 4G0Z

  • PubMed Abstract:
  • The 5'-nucleotide of small RNAs associates directly with the MID domain of Argonaute (AGO) proteins. In humans, the identity of the 5'-base is sensed by the MID domain nucleotide specificity loop and regulates the integrity of miRNAs. In Arabidopsis ...

    The 5'-nucleotide of small RNAs associates directly with the MID domain of Argonaute (AGO) proteins. In humans, the identity of the 5'-base is sensed by the MID domain nucleotide specificity loop and regulates the integrity of miRNAs. In Arabidopsis thaliana, the 5'-nucleotide also controls sorting of small RNAs into the appropriate member of the AGO family; however, the structural basis for this mechanism is unknown. Here, we present crystal structures of the MID domain from three Arabidopsis AGOs, AtAGO1, AtAGO2 and AtAGO5, and characterize their interactions with nucleoside monophosphates (NMPs). In AtAGOs, the nucleotide specificity loop also senses the identity of the 5'-nucleotide but uses more diverse modes of recognition owing to the greater complexity of small RNAs found in plants. Binding analyses of these interactions reveal a strong correlation between their affinities and evolutionary conservation.


    Organizational Affiliation

    Department of Biochemistry, McGill University, Montreal, Quebec, Canada.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Protein argonaute 1
A
147Arabidopsis thalianaGene Names: AGO1
Find proteins for O04379 (Arabidopsis thaliana)
Go to Gene View: AGO1
Go to UniProtKB:  O04379
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
U5P
Query on U5P

Download SDF File
Download CCD File
A
URIDINE-5'-MONOPHOSPHATE
C9 H13 N2 O9 P
DJJCXFVJDGTHFX-XVFCMESISA-N
 Ligand Interaction
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
U5PKd: 980000 nM BINDINGMOAD
U5PKd: 980000 nM PDBBIND
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.8 Å
  • R-Value Free: 0.216
  • R-Value Work: 0.175
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 37.291α = 90.00
b = 60.842β = 90.00
c = 69.076γ = 90.00
Software Package:
Software NamePurpose
PHENIXmodel building
HKL-2000data collection
HKL-2000data scaling
HKL-2000data reduction
PHENIXphasing
PHENIXrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2012-07-25
    Type: Initial release
  • Version 1.1: 2012-08-29
    Type: Database references
  • Version 1.2: 2012-09-12
    Type: Database references
