4EYJ

MAPK13 Complex with inhibitor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.275
  • R-Value Work: 0.242
  • R-Value Observed: 0.244

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

IL-13-induced airway mucus production is attenuated by MAPK13 inhibition.

Alevy, Y.G.Patel, A.C.Romero, A.G.Patel, D.A.Tucker, J.Roswit, W.T.Miller, C.A.Heier, R.F.Byers, D.E.Brett, T.J.Holtzman, M.J.

(2012) J Clin Invest 122: 4555-4568

  • DOI: 10.1172/JCI64896
  • Primary Citation of Related Structures:
    4EYJ, 4EYM, 4YNO

  • PubMed Abstract:
  • Increased mucus production is a common cause of morbidity and mortality in inflammatory airway diseases, including asthma, chronic obstructive pulmonary disease (COPD), and cystic fibrosis. However, the precise molecular mechanisms for pathogenic mucus production are largely undetermined ...

    Increased mucus production is a common cause of morbidity and mortality in inflammatory airway diseases, including asthma, chronic obstructive pulmonary disease (COPD), and cystic fibrosis. However, the precise molecular mechanisms for pathogenic mucus production are largely undetermined. Accordingly, there are no specific and effective anti-mucus therapeutics. Here, we define a signaling pathway from chloride channel calcium-activated 1 (CLCA1) to MAPK13 that is responsible for IL-13-driven mucus production in human airway epithelial cells. The same pathway was also highly activated in the lungs of humans with excess mucus production due to COPD. We further validated the pathway by using structure-based drug design to develop a series of novel MAPK13 inhibitors with nanomolar potency that effectively reduced mucus production in human airway epithelial cells. These results uncover and validate a new pathway for regulating mucus production as well as a corresponding therapeutic approach to mucus overproduction in inflammatory airway diseases.


    Organizational Affiliation

    Drug Discovery Program, Pulmonary and Critical Care Medicine, Department of Medicine, Washington University School of Medicine, St. Louis, Missouri 63110, USA.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Mitogen-activated protein kinase 13A371Homo sapiensMutation(s): 0
Gene Names: MAPK13PRKM13SAPK4
EC: 2.7.11.24
UniProt & NIH Common Fund Data Resources
Find proteins for O15264 (Homo sapiens)
Explore O15264
Go to UniProtKB:  O15264
PHAROS:  O15264
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
N61 (Subject of Investigation/LOI)
Query on N61

Download Ideal Coordinates CCD File
B [auth A]1-(3-tert-butyl-1-methyl-1H-pyrazol-5-yl)-3-[4-(pyridin-4-yloxy)phenyl]urea
C20 H23 N5 O2
MHSLDASSAFCCDO-UHFFFAOYSA-N
 Ligand Interaction
Binding Affinity Annotations
IDSourceBinding Affinity
N61 PDBBind:  4EYJ IC50: 620 (nM) from 1 assay(s)
BindingDB:  4EYJ IC50: min: 82.72, max: 619.5 (nM) from 2 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.275
  • R-Value Work: 0.242
  • R-Value Observed: 0.244
  • Space Group: P 21 21 21
  • Diffraction Data DOI: 10.15785/SBGRID/88 SBGrid
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 60.855α = 90
b = 69.955β = 90
c = 92.807γ = 90
Software Package:
Software NamePurpose
Blu-Icedata collection
PHENIXmodel building
PHENIXrefinement
HKL-2000data reduction
SCALEPACKdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2012-12-19
    Type: Initial release
