4ENN

Crystal structure of S. pombe Atl1 in complex with damaged DNA containing O6-carboxymethylguanine


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.8448 Å
  • R-Value Free: 0.278
  • R-Value Work: 0.217

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Atl1 Regulates Choice between Global Genome and Transcription-Coupled Repair of O(6)-Alkylguanines.

Latypov, V.F.Tubbs, J.L.Watson, A.J.Marriott, A.S.McGown, G.Thorncroft, M.Wilkinson, O.J.Senthong, P.Butt, A.Arvai, A.S.Millington, C.L.Povey, A.C.Williams, D.M.Santibanez-Koref, M.F.Tainer, J.A.Margison, G.P.

(2012) Mol.Cell 47: 50-60

  • DOI: 10.1016/j.molcel.2012.04.028
  • Primary Citation of Related Structures:  4ENJ, 4ENK, 4ENM

  • PubMed Abstract:
  • Nucleotide excision repair (NER) has long been known to remove DNA lesions induced by chemical carcinogens, and the molecular mechanism has been partially elucidated. Here we demonstrate that in Schizosaccharomyces pombe a DNA recognition protein, al ...

    Nucleotide excision repair (NER) has long been known to remove DNA lesions induced by chemical carcinogens, and the molecular mechanism has been partially elucidated. Here we demonstrate that in Schizosaccharomyces pombe a DNA recognition protein, alkyltransferase-like 1 (Atl1), can play a pivotal role in selecting a specific NER pathway, depending on the nature of the DNA modification. The relative ease of dissociation of Atl1 from DNA containing small O(6)-alkylguanines allows accurate completion of global genome repair (GGR), whereas strong Atl1 binding to bulky O(6)-alkylguanines blocks GGR, stalls the transcription machinery, and diverts the damage to transcription-coupled repair. Our findings redraw the initial stages of the NER process in those organisms that express an alkyltransferase-like gene and raise the question of whether or not O(6)-alkylguanine lesions that are poor substrates for the alkyltransferase proteins in higher eukaryotes might, by analogy, signal such lesions for repair by NER.


    Organizational Affiliation

    Cancer Research UK Carcinogenesis Group, Paterson Institute for Cancer Research, University of Manchester, Manchester M20 4BX, UK.




Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Alkyltransferase-like protein 1
A, B
116Schizosaccharomyces pombe (strain 972 / ATCC 24843)Gene Names: atl1
Find proteins for Q9UTN9 (Schizosaccharomyces pombe (strain 972 / ATCC 24843))
Go to UniProtKB:  Q9UTN9
Entity ID: 2
MoleculeChainsLengthOrganism
RNA (5'-R(*GP*CP*CP*AP*TP*GP*(C6G)P*CP*TP*AP*GP*TP*A)-3')C,D,E,F13synthetic construct
Small Molecules
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
C6G
Query on C6G
C, D, E, F
DNA LINKINGC12 H16 N5 O9 PDG
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.8448 Å
  • R-Value Free: 0.278
  • R-Value Work: 0.217
  • Space Group: P 41 21 2
Unit Cell:
Length (Å)Angle (°)
a = 85.154α = 90.00
b = 85.154β = 90.00
c = 150.715γ = 90.00
Software Package:
Software NamePurpose
PHASERphasing
HKL-2000data collection
PHENIXrefinement
HKL-2000data scaling
HKL-2000data reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2012-06-20
    Type: Initial release
  • Version 1.1: 2012-08-01
    Type: Database references
  • Version 1.2: 2017-03-29
    Type: Structure summary
