4DWU | pdb_00004dwu

Carbonmonoxy dehaloperoxidase-hemoglobin A structure at 1.44 Angstrom resolution

• PDB DOI: https://doi.org/10.2210/pdb4DWU/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Amphitrite ornata
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2012-02-26 Released: 2013-02-27
• Deposition Author(s): de Serrano, V.S., Zhao, J., Franzen, S.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.44 Å
• R-Value Free:
  0.202 (Depositor), 0.196 (DCC)
• R-Value Work:
  0.179 (Depositor), 0.176 (DCC)
• R-Value Observed:
  0.181 (Depositor)

Starting Model: experimental

Literature

A unique role for the distal histidine observed in carbonmonoxy dehaloperoxidase-hemoglobin A structures

de Serrano, V.S., Zhao, J., Franzen, S.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 32.87 kDa
• Atom Count: 3,360
• Modeled Residue Count: 274
• Deposited Residue Count: 274
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Dehaloperoxidase A	A, B	137	Amphitrite ornata	Mutation(s): 0  Gene Names: dhpA EC: 1.11
UniProt
Find proteins for Q9NAV8 (Amphitrite ornata) Explore Q9NAV8  Go to UniProtKB:  Q9NAV8

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
HEM	C [auth A], J [auth B]	PROTOPORPHYRIN IX CONTAINING FE C34 H32 Fe N4 O4 KABFMIBPWCXCRK-RGGAHWMASA-L
SO4	E [auth A], F [auth A], G [auth A], H [auth A], I [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
CMO	D [auth A], K [auth B]	CARBON MONOXIDE C O UGFAIRIUMAVXCW-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.44 Å
• R-Value Free:  0.202 (Depositor), 0.196 (DCC)
• R-Value Work:  0.179 (Depositor), 0.176 (DCC)
• R-Value Observed: 0.181 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 57.922	α = 90
b = 67.622	β = 90
c = 68.391	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data collection
PHASER	phasing
REFMAC	refinement
DENZO	data reduction
SCALEPACK	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2013-02-27
Deposition Author(s): de Serrano, V.S., Zhao, J., Franzen, S.

Revision History

• Version 1.0: 2013-02-27
  Type: Initial release

• Version 1.1: 2023-09-13
  Changes: Data collection, Database references, Derived calculations, Refinement description
