4DWF

Crystal structure of a HLA-B associated transcript 3 (BAT3) from Homo sapiens at 1.80 A resolution

• PDB DOI: https://doi.org/10.2210/pdb4DWF/pdb

• Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2012-02-24 Released: 2012-03-28
• Deposition Author(s): Joint Center for Structural Genomics (JCSG), Partnership for T-Cell Biology (TCELL)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free: 0.241
• R-Value Work: 0.182
• R-Value Observed: 0.185

Literature

Crystal structure of a HLA-B associated transcript 3 (BAT3) from Homo sapiens at 1.80 A resolution

Joint Center for Structural Genomics (JCSG), Partnership for T-Cell Biology (TCELL)

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 20.3 kDa
• Atom Count: 1,470
• Modelled Residue Count: 158
• Deposited Residue Count: 180
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
HLA-B-associated transcript 3	A, B	90	Homo sapiens	Mutation(s): 0  Gene Names: BAG6, BAT3, BC003133, G3
UniProt & NIH Common Fund Data Resources
Find proteins for P46379 (Homo sapiens) Explore P46379  Go to UniProtKB:  P46379
PHAROS:  P46379 GTEx:  ENSG00000204463

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	C [auth A], D [auth A], E [auth B], F [auth B]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free: 0.241
• R-Value Work: 0.182
• R-Value Observed: 0.185
• Space Group: P 2₁ 2₁ 2
• Diffraction Data: https://doi.org/10.18430/M34DWF

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 61.32	α = 90
b = 74.09	β = 90
c = 43.119	γ = 90

Software Package:

Software Name	Purpose
MolProbity	model building
PDB_EXTRACT	data extraction
SHELX	phasing
SHARP	phasing
XSCALE	data scaling
REFMAC	refinement
XDS	data reduction
SHELXD	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2012-03-28
Deposition Author(s): Joint Center for Structural Genomics (JCSG), Partnership for T-Cell Biology (TCELL)

Revision History

• Version 1.0: 2012-03-28
  Type: Initial release

• Version 1.1: 2015-10-21
  Changes: Structure summary
• Version 1.2: 2017-11-15
  Changes: Refinement description
• Version 1.3: 2023-02-01
  Changes: Database references, Derived calculations
• Version 1.4: 2024-11-20
  Changes: Data collection, Structure summary
