4DRY | pdb_00004dry

The crystal structure of 3-oxoacyl-[acyl-carrier-protein] reductase from Rhizobium meliloti

• PDB DOI: https://doi.org/10.2210/pdb4DRY/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Sinorhizobium meliloti 1021
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2012-02-17 Released: 2012-02-29
• Deposition Author(s): Zhang, Z., Chamala, S., Evans, B., Foti, R., Gizzi, A., Hillerich, B., Kar, A., LaFleur, J., Seidel, R., Villigas, G., Zencheck, W., Almo, S.C., Swaminathan, S., New York Structural Genomics Research Consortium (NYSGRC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.50 Å
• R-Value Free:
  0.264 (Depositor), 0.259 (DCC)
• R-Value Work:
  0.206 (Depositor), 0.202 (DCC)
• R-Value Observed:
  0.209 (Depositor)

Literature

The crystal structure of 3-oxoacyl-[acyl-carrier-protein] reductase from Rhizobium meliloti

Zhang, Z., Almo, S.C., Swaminathan, S.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 119.62 kDa
• Atom Count: 7,356
• Modeled Residue Count: 985
• Deposited Residue Count: 1,124
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
3-oxoacyl-[acyl-carrier-protein] reductase	A, B, C, D	281	Sinorhizobium meliloti 1021	Mutation(s): 0  Gene Names: RB1369, SM_b20662 EC: 1.1.1.100
UniProt
Find proteins for Q92TX5 (Rhizobium meliloti (strain 1021)) Explore Q92TX5  Go to UniProtKB:  Q92TX5

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	E [auth A], F [auth B], G [auth C], H [auth D]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B, C, D	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.50 Å
• R-Value Free:  0.264 (Depositor), 0.259 (DCC)
• R-Value Work:  0.206 (Depositor), 0.202 (DCC)
• R-Value Observed: 0.209 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 86.531	α = 90
b = 98.128	β = 90
c = 117.22	γ = 90

Software Package:

Software Name	Purpose
CBASS	data collection
SOLVE	phasing
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2012-02-29
Deposition Author(s): Zhang, Z., Chamala, S., Evans, B., Foti, R., Gizzi, A., Hillerich, B., Kar, A., LaFleur, J., Seidel, R., Villigas, G., Zencheck, W., Almo, S.C., Swaminathan, S., New York Structural Genomics Research Consortium (NYSGRC)

Revision History

• Version 1.0: 2012-02-29
  Type: Initial release

• Version 1.1: 2024-11-27
  Changes: Data collection, Database references, Derived calculations, Structure summary
