4DKZ

Hairpin structure of a DNA dodecamer containing North-methanocarba-2'-deoxythymidine

  • Classification: DNA
  • Mutation(s): No

  • Deposited: 2012-02-05 Released: 2012-03-28
  • Deposition Author(s): Egli, M., Pallan, P.S.

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.252
  • R-Value Work: 0.234

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

The Conformationally Constrained N-Methanocarba-dT Analogue Adopts an Unexpected C4'-exo Sugar Pucker in the Structure of a DNA Hairpin.

Pallan, P.S.Marquez, V.E.Egli, M.

(2012) Biochemistry 51: 2639-2641

  • DOI: https://doi.org/10.1021/bi300215k
  • Primary Citation of Related Structures:
    4DKZ

  • PubMed Abstract:

    Incorporation of a bicyclo[3.1.0]hexane scaffold into the nucleoside sugar was devised to lock the embedded cyclopentane ring in conformations that mimic the furanose North and South sugar puckers. To analyze the effects of North-methanocarba-2'-deoxythymidine (N-MCdT) on the B-form DNA, we crystallized d(CGCGAA[mcTmcT]CGCG) with two N-MCdTs. Instead of a duplex, the 12mer forms a tetraloop hairpin, whereby loop N-MCdTs adopt the C4'-exo pucker (NE; P = 50°). Thus, the bicyclic framework does not limit the pucker to the anticipated C2'-exo range (NNW; P = -18°).


  • Organizational Affiliation

    Department of Biochemistry, Vanderbilt University, School of Medicine, Nashville, Tennessee 37232, United States.


Macromolecules

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 1
MoleculeChains LengthOrganismImage
Synthetic DNA dodecamer containg North-methanocarba-2'-deoxythymidine (N-MCdT)
A, B
12N/A
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.252
  • R-Value Work: 0.234
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 24.3α = 90
b = 35.28β = 92.84
c = 36.71γ = 90
Software Package:
Software NamePurpose
MD2data collection
CNSrefinement
HKL-2000data reduction
HKL-2000data scaling
CNSphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2012-03-28
    Type: Initial release
  • Version 1.1: 2012-04-04
    Changes: Derived calculations
  • Version 1.2: 2012-04-18
    Changes: Database references
  • Version 1.3: 2024-02-28
    Changes: Data collection, Database references, Derived calculations
